Introduction to Soil Data Access (SDA)
The Soil Data Access (SDA) system provides REST-based access to the SSURGO and STATSGO2 databases maintained by USDA-NRCS. Instead of downloading large databases, SDA allows you to query exactly what you need via a web service.
soilDB provides several functions that help with
generating requests to the web service at a low level, as well as
higher-level functions that can return complex data structures like the
SoilProfileCollection from the aqp package or
spatial object types.
What is SDA?
SDA provides access to a SQL Server database containing a variety of soil information:
- Tabular data: map units, components, horizons, interpretations, ecological classes, laboratory characterization results, and more
- Spatial data: map unit polygons with geometry (available via WKT or for spatial queries), point locations (XY coordinates)
The SDA REST endpoint is available at:
https://sdmdataaccess.sc.egov.usda.gov/tabular/post.restAll queries to SDA are executed through the SDA_query()
function in soilDB, which handles the HTTP POST requests
and JSON response parsing automatically.
SSURGO and STATSGO2 Data
SDA contains both the detailed Soil Survey Geographic Database (SSURGO) and the generalized U.S. General Soil Map (STATSGO2).
-
SSURGO: Detailed mapping (scales 1:12,000 to
1:24,000). Identified by specific area symbols (e.g.,
CA630,IN005). -
STATSGO2: Generalized mapping (scale 1:250,000) for
regional/national analysis. Identified by the single area symbol
'US'.
See the Data Filters section below for details on filtering out STATSGO2 data.
When to Use SDA vs. Local SSURGO
Use SDA for current data from NRCS without manual downloads, queries across multiple survey areas, quick one-time analyses, or access to interpretations and aggregated properties. Use local SSURGO databases for repeated queries to the same survey areas (faster), offline access, complete survey databases with all tables, or direct SQLite manipulation.
The same get_SDA_*() functions documented in this
vignette can be applied to local SSURGO databases by passing the
dsn parameter. See the Local
SSURGO vignette for downloading and creating local SSURGO GeoPackage
databases, and for examples of using these functions with local
data.
Package Requirements
For spatial data examples, use sf and
terra, which are both optional but recommended.
install.packages(c("sf", "terra"))Basic SDA_query() Function
Core Syntax
The SDA_query() function executes SQL queries directly
against the SDA database:
# Simple query to get the first 5 map units from an area
q <- "
SELECT TOP 5
mapunit.mukey,
mapunit.nationalmusym,
legend.areasymbol,
mapunit.musym,
mapunit.muname
FROM legend
INNER JOIN mapunit ON mapunit.lkey = legend.lkey
WHERE legend.areasymbol = 'CA630'
ORDER BY mapunit.musym
"
result <- SDA_query(q)
head(result)## mukey nationalmusym areasymbol musym
## 1 2403709 2lp80 CA630 1012
## 2 2924914 2x4d4 CA630 1013
## 3 2924833 2x297 CA630 1090
## 4 2924834 2x298 CA630 1091
## 5 2924907 2x8lf CA630 128
## muname
## 1 Mined land
## 2 Mined land-Anthraltic Xerorthents complex, 1 to 15 percent slopes
## 3 Ultic Haploxeralfs-Mollic Haploxeralfs complex, 3 to 30 percent slopes
## 4 Ultic Haploxeralfs-Aquic Dystroxerepts complex, 2 to 8 percent slopes
## 5 Cogna loam, 0 to 2 percent slopes, overwashHandling Errors
If SDA_query() errors for any reason, the result will
not be a data.frame with data. Instead it will be an object of class
"try-error". You can handle the possibility of error using
inherits(). For example:
result <- SDA_query(q)
# check if the result is an error response
if (!inherits(result, 'try-error')){
head(result)
} else {
# stop with error message extracted from result
stop("Error occured! ", result[1])
}## mukey nationalmusym areasymbol musym
## 1 2403709 2lp80 CA630 1012
## 2 2924914 2x4d4 CA630 1013
## 3 2924833 2x297 CA630 1090
## 4 2924834 2x298 CA630 1091
## 5 2924907 2x8lf CA630 128
## muname
## 1 Mined land
## 2 Mined land-Anthraltic Xerorthents complex, 1 to 15 percent slopes
## 3 Ultic Haploxeralfs-Mollic Haploxeralfs complex, 3 to 30 percent slopes
## 4 Ultic Haploxeralfs-Aquic Dystroxerepts complex, 2 to 8 percent slopes
## 5 Cogna loam, 0 to 2 percent slopes, overwashYou can set up a loop to retry a query that fails in the event of
intermittent network or server issues. You should have a brief period of
wait time (Sys.sleep()) between requests.
For repeated failures, it is best to increase that wait time in between each try up to, for example, a maximum of 3 attempts. The following example uses “exponential backoff” which increases the wait time in between requests incrementally from ~3 seconds to ~20 seconds over the course of several attempts.
n_tries <- 1
while (n_tries <= 3){
result <- SDA_query(q)
# check if the result is an error response
if (!inherits(result, 'try-error')){
head(result)
# if no error, break out of the loop
break
} else {
# on error, increment the number of tries
# and sleep (time in seconds)
Sys.sleep(exp(n_tries))
n_tries <- n_tries + 1
if (n_tries > 3) {
stop("Error occured! ", result[1])
}
}
}Understanding SDA SQL
SDA uses Microsoft SQL Server Transact-SQL (T-SQL) dialect.
Key differences of T-SQL from SQLite and other SQL dialects that are relevant to queries used in soilDB include:
| Feature | T-SQL | SQLite | Notes |
|---|---|---|---|
| Row limit | TOP 10 |
LIMIT 10 |
Place after SELECT |
| NULL functions | ISNULL(col, 0) |
IFNULL(col, 0) |
Different function names |
| String concatenation | col1 + col2 |
col1 || col2 |
Different operators |
When using SDA_query() with a local SQLite
database (via dsn parameter), soilDB
automatically converts some T-SQL syntax to SQLite equivalents to allow
for both to work. This behavior is triggered when the dsn
argument is specified. You can view the queries (and save them to run
yourself) by passing the query_string=TRUE argument.
Basic Table Joins
Many custom SSURGO queries follow a standard pattern of relationships from legend, to mapunit, to component, to a related table to component such as component horizon.
In SSURGO data model primary and foreign key physical column names
all end with the word "key". The primary key is a unique
identifier of a particular record.
Foreign keys are references to primary keys of other tables and define the relationships between tables that can be used for joins.
Here we select a handful of values from all of the above mentioned
tables corresponding to the first 10 component horizon
(chorizon) in the SDA table.
# Get map unit, component, and horizon data
q <- "
SELECT TOP 10
mu.mukey,
leg.areasymbol,
mu.musym,
co.compname,
co.comppct_r,
ch.hzname,
ch.hzdept_r,
ch.hzdepb_r,
ch.claytotal_r
FROM legend AS leg
INNER JOIN mapunit AS mu ON mu.lkey = leg.lkey
INNER JOIN component AS co ON co.mukey = mu.mukey
LEFT JOIN chorizon AS ch ON ch.cokey = co.cokey
WHERE leg.areasymbol = 'CA630'
AND co.majcompflag = 'Yes'
AND ch.claytotal_r IS NOT NULL
ORDER BY mu.musym, co.comppct_r DESC, ch.hzdept_r
"
result <- SDA_query(q)
head(result, 10)## mukey areasymbol musym compname comppct_r hzname hzdept_r
## 1 2924914 CA630 1013 Anthraltic Xerorthents 30 ^A 0
## 2 2924914 CA630 1013 Anthraltic Xerorthents 30 ^AC 3
## 3 2924914 CA630 1013 Anthraltic Xerorthents 30 ^C 23
## 4 2924833 CA630 1090 Ultic Haploxeralfs 60 A 0
## 5 2924833 CA630 1090 Ultic Haploxeralfs 60 BA 8
## 6 2924833 CA630 1090 Ultic Haploxeralfs 60 Bt1 24
## 7 2924833 CA630 1090 Ultic Haploxeralfs 60 Bt2 61
## 8 2924833 CA630 1090 Ultic Haploxeralfs 60 Ct 100
## 9 2924833 CA630 1090 Mollic Haploxeralfs 30 A 0
## 10 2924833 CA630 1090 Mollic Haploxeralfs 30 Bt1 6
## hzdepb_r claytotal_r
## 1 3 5
## 2 23 3
## 3 100 2
## 4 8 12
## 5 24 15
## 6 61 18
## 7 100 25
## 8 152 29
## 9 6 16
## 10 27 18We supplied all of the filtering constraints in a WHERE
clause for clarity, with joins only using primary and foreign keys.
In general, the same constraints can be expressed as part of a join to relevant tables, which can be more efficient in complex queries.
Understanding LEFT JOIN vs INNER JOIN
One of the most important considerations in SSURGO queries is data completeness: not all relationships in the SSURGO database are populated for all soils or components. Understanding when to use LEFT JOIN vs. INNER JOIN is critical for correct analysis.
When Data are Complete: INNER JOIN
Use INNER JOIN when the relationship must
exist for meaningful results:
# These relationships are always present in SSURGO:
# - mapunit always belongs to a legend (survey area)
# - component always belongs to a mapunit
q <- "
SELECT TOP 10
leg.areasymbol,
mu.musym,
co.compname,
co.comppct_r
FROM legend AS leg
INNER JOIN mapunit AS mu ON mu.lkey = leg.lkey
INNER JOIN component AS co ON co.mukey = mu.mukey
WHERE leg.areasymbol = 'CA630'
ORDER BY mu.musym, co.comppct_r DESC
"
result <- SDA_query(q)
# Every row represents a valid component with all parent relationships
head(result)## areasymbol musym compname comppct_r
## 1 CA630 1012 Mined land 94
## 2 CA630 1012 Water 6
## 3 CA630 1013 Mined land 70
## 4 CA630 1013 Anthraltic Xerorthents 30
## 5 CA630 1090 Ultic Haploxeralfs 60
## 6 CA630 1090 Mollic Haploxeralfs 30When Data May Be Missing: LEFT JOIN
Use LEFT JOIN when a parent record may exist
without child records. Two example cases:
Case 1: Components Without Horizons Some soil
components in SSURGO do not have associated horizon
data. These are often “non-soil” components (compkind
“Miscellaneous Area”) or minor components (majcompflag
“No”) which may lack detailed horizon description:
# Some components have NO horizons defined
# INNER JOIN would exclude these components entirely
# LEFT JOIN preserves components even without horizon data
q <- "
SELECT
leg.areasymbol,
mu.mukey,
mu.musym,
co.compname,
co.comppct_r,
ch.chkey,
ch.hzdept_r,
ch.hzdepb_r
FROM legend AS leg
INNER JOIN mapunit AS mu ON mu.lkey = leg.lkey
INNER JOIN component AS co ON co.mukey = mu.mukey
LEFT JOIN chorizon AS ch ON ch.cokey = co.cokey
WHERE leg.areasymbol = 'CA630'
AND co.majcompflag = 'Yes'
ORDER BY mu.musym, co.comppct_r DESC, ch.hzdept_r
"
result <- SDA_query(q)
# Check for components without horizons:
# Rows with NA in horizon columns indicate a component with no horizon data
if (is.data.frame(result) && nrow(result) > 0) {
components_no_horizons <- result[is.na(result$chkey), ]
if (nrow(components_no_horizons) > 0) {
cat('Found', nrow(components_no_horizons), 'components without horizon data:\n')
print(components_no_horizons[, c('musym', 'compname', 'comppct_r')])
}
}## Found 29 components without horizon data:
## musym compname comppct_r
## 1 1012 Mined land 94
## 2 1013 Mined land 70
## 59 3020 Rock outcrop 15
## 69 3021 Rock outcrop 15
## 116 3046 Rock outcrop 20
## 269 5016 Rock outcrop 20
## 341 6029 Rock outcrop 25
## 550 6076 Rock outcrop 25
## 786 7091 Rock outcrop 11
## 796 7092 Rock outcrop 15
## 857 7166 Rock outcrop 12
## 935 8110 Riverwash 20
## 944 8111 Riverwash 15
## 1166 8289 Rock outcrop 25
## 1197 8314 Rock outcrop 40
## 1211 8317 Rock outcrop 35
## 1217 8318 Rock outcrop 25
## 1227 8319 Rock outcrop 35
## 1236 9010 Urban land 85
## 1237 9011 Urban land 50
## 1249 9012 Urban land 65
## 1254 9013 Urban land 50
## 1260 9014 Urban land 50
## 1271 9015 Urban land 50
## 1283 9016 Urban land 50
## 1298 9017 Urban land 60
## 1302 9018 Urban land 65
## 1310 DAM Dams 100
## 1311 W Water 100Comparison: INNER JOIN would have excluded those components:
# Using INNER JOIN on horizons drops components that lack horizon data
q_inner <- "
SELECT
leg.areasymbol,
mu.mukey,
mu.musym,
co.compname,
co.comppct_r,
ch.desgnmaster,
ch.hzdept_r,
ch.hzdepb_r
FROM legend AS leg
INNER JOIN mapunit AS mu ON mu.lkey = leg.lkey
INNER JOIN component AS co ON co.mukey = mu.mukey
INNER JOIN chorizon AS ch ON ch.cokey = co.cokey
WHERE leg.areasymbol = 'CA630'
AND co.majcompflag = 'Yes'
ORDER BY mu.musym, co.comppct_r DESC, ch.hzdept_r
"
result_inner <- SDA_query(q_inner)
# number of rows in LEFT JOIN result
nrow(result)## [1] 1311
# number of rows in INNER JOIN result
nrow(result_inner)## [1] 1282Case 2: Horizons Without Rock Fragments
Similarly, not all horizons have child table rock fragment volume recorded. An empty chfrags table is conventionally used for horizons with no fragments, but in some cases may be used for soils that have non-zero fragment weight fractions (for example, those with human artifacts). When you need to include horizons regardless of fragment availability, use LEFT JOIN:
# Some horizons have NO rock fragment data recorded
# LEFT JOIN preserves horizons even without fragment information
q <- "
SELECT
mu.musym,
co.compname,
ch.desgnmaster,
ch.hzdept_r,
ch.hzdepb_r,
rf.fragsize_h,
rf.fragvol_r
FROM legend AS leg
INNER JOIN mapunit AS mu ON mu.lkey = leg.lkey
INNER JOIN component AS co ON co.mukey = mu.mukey
LEFT JOIN chorizon AS ch ON ch.cokey = co.cokey
LEFT JOIN chfrags AS rf ON rf.chkey = ch.chkey
WHERE leg.areasymbol = 'CA630'
AND co.majcompflag = 'Yes'
ORDER BY mu.musym, co.comppct_r DESC, ch.hzdept_r
"
result <- SDA_query(q)
# Check for horizons without fragments:
if (is.data.frame(result) && nrow(result) > 0) {
horizons_no_frags <- result[!duplicated(result$chkey) & is.na(result$fragsize_h), ]
if (nrow(horizons_no_frags) > 0) {
cat('Found', nrow(horizons_no_frags), 'horizons without rock fragment data:\n')
print(horizons_no_frags[, c('musym', 'compname', 'desgnmaster', 'fragvol_r')])
}
}Summary: When to Use Each Join Type
| Situation | Join Type | Reason |
|---|---|---|
| Query result must have values at all levels | INNER | Filter out incomplete records |
| Parent may exist without children (components without horizons, horizons without fragments) | LEFT | Preserve parent records even when children are missing |
| Calculating aggregations (COUNT, SUM, AVG) with missing data | Depends | LEFT includes zero-occurrence groups; INNER ignores them |
| Applying WHERE filters to child tables | Typically LEFT | INNER JOIN combined with WHERE can lose parents unintentionally |
Tip: When using LEFT JOIN, always check for
NA values in child table columns to identify records with
missing child data.
Aggregation Functions
SDA supports standard SQL aggregate functions (COUNT, SUM, AVG, MIN, MAX, etc.):
# Get component statistics per map unit
q <- "
SELECT
mu.mukey,
mu.musym,
mu.muname,
COUNT(co.cokey) AS n_components,
SUM(co.comppct_r) AS total_comppct,
AVG(co.comppct_r) AS avg_comppct
FROM legend AS leg
INNER JOIN mapunit AS mu ON mu.lkey = leg.lkey
INNER JOIN component AS co ON co.mukey = mu.mukey
WHERE leg.areasymbol = 'CA630'
GROUP BY mu.mukey, mu.musym, mu.muname
ORDER BY mu.musym
"
result <- SDA_query(q)
head(result)## mukey musym
## 1 2403709 1012
## 2 2924914 1013
## 3 2924833 1090
## 4 2924834 1091
## 5 2924907 128
## 6 2924879 206
## muname
## 1 Mined land
## 2 Mined land-Anthraltic Xerorthents complex, 1 to 15 percent slopes
## 3 Ultic Haploxeralfs-Mollic Haploxeralfs complex, 3 to 30 percent slopes
## 4 Ultic Haploxeralfs-Aquic Dystroxerepts complex, 2 to 8 percent slopes
## 5 Cogna loam, 0 to 2 percent slopes, overwash
## 6 Pentz sandy loam, 2 to 15 percent slopes
## n_components total_comppct avg_comppct
## 1 2 100 50
## 2 2 100 50
## 3 6 100 16
## 4 2 100 50
## 5 6 100 16
## 6 8 100 12Here we use SQL GROUP BY to define the columns used to
determine unique groups. Other columns that are not part of the GROUP BY
statement need to be included in some sort of aggregation expression to
be used in SELECT clause.
When calculating map unit weighted averages using custom SQL, be
aware that comppct_r (Component Percentage) does not always
sum to 100% for a map unit due to minor component inclusions that may
not be exported or missing data.
A robust weighted average should normalize weights by the sum of component percentages present in the data, rather than assuming a sum of 100. This is especially important if you are relying on INNER JOIN to chorizon table, as many mapunits have at least some components with no horizon data.
Data Filters
Filtering SSURGO vs. STATSGO2
When querying SDA, especially without specific map unit keys or area symbols, it is often important to exclude STATSGO2 data to prevent mixing these two distinct datasets.
Common filter to exclude STATSGO2:
Filtering Horizon Data
When aggregating soil properties, it is sometimes important to exclude layers that do not represent mineral soil so that depth-weighted averages and other statistics are not skewed.
Note that if zero values are present for a soil property they can
drag down averages. If you include a weighting factor in a custom query
for the thickness of a layer with a NULL value, that is
essentially the same as if the property value were 0.
The two most common types of non-mineral soil layers to exclude are:
Bedrock and other Root-Limiting Layers: Below the “bottom of the soil” (e.g.,
R,Crhorizons).Dry Surface Organic Layers (Duff): High-carbon, low bulk density, dry organic (O) horizons
Filtering Strategy
Since SSURGO data spans decades of standards, no single column perfectly identifies these non-soil layers.
The safest approach is to use the new computed horztype
column in combination with in lieu texture class codes.
Currently horztype only supports identification of dry
organic layers on the surface, but it may be extended to other material
types in the future.
1. Filter Bedrock:
Bedrock layers often have NULL property values, which is
not much of a problem provided there are data available for the
overlying soil layers; but you will need to exclude the thickness of the
bedrock layers for accurate depth-weighted average calculations.
The horztype column does not capture bedrock. You must
filter by texture code:
This includes the modern “bedrock” (BR), as well as the obsolete “weathered bedrock” and “unweathered bedrock”. For the purposes of excluding non-soil bedrock material, they can be treated as equivalent and will cover many cases.
There are a variety of other “in lieu” texture codes that are used to identify cemented materials (“CEM”, “IND”, “MAT”) which may or may not have other texture information and may also need to be considered for exclusion.
While it might be tempting to just filter on horizon designation (e.g. excluding R or Cr layers explicitly), as discussed below this is not completely reliable on its own.
2. Filter Dry Organics (Duff):
The horztype column is currently primarily for
identifying “Dry Organic” layers. This is a new column that has been
programmatically populated to help users filter out a common set of
data.
Combine horztype with texture codes like
"SPM" (which is the least-decomposed organic soil material:
dry fibric material) for more robust confirmation of filtering logic.
You can also include "MPM" and "HPM" if you
are interested in excluding even more decomposed dry organic
materials:
/* Exclude "Duff" / Dry Organics */
AND ISNULL(horztype, '') != 'Dry Organic'
AND texturerv NOT IN ('SPM', 'MPM', 'HPM') The population of O horizons in SSURGO is inconsistent due to evolving data collection standards. While modern surveys often include numerical data for organic surface layers, legacy data may only mention them in descriptions without populated properties.
Retain these layers when analyzing data completeness or identifying diagnostic features like folistic epipedons. However, for analyses focused on mineral soil properties, excluding them is often necessary to prevent skewing depth-weighted averages.
Note: We generally want to keep “Wet Organic” layers (PEAT, MPT [mucky peat], and MUCK) as these may be diagnostic for Histosols, Histic epipedons etc., which are important concepts for identification of hydric soils.
3. Filter by Horizon Designation
It is also possible, but not completely reliable due to soil survey vintage and patterns in historical data population, to filter by horizon designation.
For instance, a logical statement to exclude the master horizon designation “O” for organics:
While using horizon designations is conceptually appealing, it is problematic when it is the only logic you are using. Horizon designations were not historically populated for the aggregate soil component data (SSURGO).
In the last two decades layers in the chorizon table
have been assigned morphologic horizon designations, but this has not
been done retroactively. Some older soil surveys still use “H” as the
master horizon designation for all layers e.g. H1, H2, H3 instead of A,
B, C. If this is the case the only way to identify bedrock, or organic
layers, is to use other data elements such as in lieu texture class.
Soil Materials
This section demonstrates filtering horizon data based on material types.
We will start with a custom query that targets components with “Histic” taxonomic subgroup formative element.
q <- "
SELECT TOP 10
component.compname,
ch.hzname,
ch.hzdept_r,
ch.hzdepb_r,
ch.texturerv,
ch.horztype,
ch.claytotal_r,
ch.om_r
FROM chorizon AS ch
INNER JOIN component ON component.cokey = ch.cokey AND taxsubgrp LIKE '%Histic%'
ORDER BY component.cokey, hzdept_r
"
result <- SDA_query(q)
result## compname hzname hzdept_r hzdepb_r texturerv horztype claytotal_r om_r
## 1 Scarboro H1 0 23 <NA> <NA> 4.0 NA
## 2 Scarboro H2 23 41 <NA> <NA> 3.0 NA
## 3 Scarboro H3 41 84 <NA> <NA> 1.0 NA
## 4 Scarboro H4 84 165 <NA> <NA> 1.0 NA
## 5 Scarboro H1 0 23 <NA> <NA> 4.0 NA
## 6 Scarboro H2 23 41 <NA> <NA> 3.0 NA
## 7 Scarboro H3 41 84 <NA> <NA> 1.0 NA
## 8 Scarboro H4 84 165 <NA> <NA> 1.0 NA
## 9 Canova H1 0 23 <NA> <NA> NA 55
## 10 Canova H2 23 56 <NA> <NA> 3.5 NAHere is a sample query to select mineral and wet organic soil layers:
q <- "
SELECT TOP 10
ch.hzname,
ch.hzdept_r,
ch.hzdepb_r,
ch.texturerv,
ch.horztype,
ch.claytotal_r,
ch.om_r
FROM chorizon AS ch
WHERE
-- 1. Exclude Bedrock
ch.texturerv NOT IN ('BR', 'WB', 'UWB')
-- 2. Exclude Dry Organic / Duff
AND ISNULL(ch.horztype, '') != 'Dry Organic'
AND ch.texturerv NOT IN ('SPM', 'MPM', 'HPM')
ORDER BY cokey, hzdept_r
"
result <- SDA_query(q)
head(result)## hzname hzdept_r hzdepb_r texturerv horztype claytotal_r om_r
## 1 Ap 0 25 SIL Other 26 2.00
## 2 A 25 36 SICL Other 31 1.75
## 3 Bg 36 96 SICL Other 31 1.00
## 4 Cg 96 135 SICL Other 37 0.75
## 5 Ab 135 152 SICL Other 37 2.00
## 6 H1 0 38 SICL Other 38 3.50In contrast to bedrock, organic soil materials are soil materials, whether they are wet or dry–but it is important to know when you may need to look past them. Organic layers have very low bulk density and very high organic carbon content, both of which can skew “mineral soil” averages if included in depth-weighted calculations.
Take for example the K factor for estimating erosion hazard: users often want properties for an exposed mineral soil surface rather than that of an organic layer over the mineral soil surface. In general, the concept of K factor does not apply to the organic surface.
To demonstrate, we will look at the whole SSURGO database. We count
the number of horizons with master designation “O” and horizon top depth
0 within groups of different combinations of
Kw and Kf, and sort in decreasing order.
q <- "
SELECT
COUNT(chkey) AS n,
kwfact,
kffact
FROM chorizon
WHERE desgnmaster = 'O' AND hzdept_r = 0
GROUP BY kwfact, kffact
ORDER BY n DESC
"
result <- SDA_query(q)
result$percent <- round(prop.table(result$n) * 100, 1)
head(result, 10)## n kwfact kffact percent
## 1 128757 <NA> <NA> 99.0
## 2 754 .02 .02 0.6
## 3 402 .05 .05 0.3
## 4 42 .10 .10 0.0
## 5 25 .15 .15 0.0
## 6 12 .17 .17 0.0
## 7 11 .28 .28 0.0
## 8 8 .24 .24 0.0
## 9 5 .37 .37 0.0
## 10 4 .10 .17 0.0This query shows that many O horizons at the soil surface have NULL K factor values.
The take away from this should be: if your analysis relies on having K factor everywhere you will either need to filter out the O horizons, or come up with a way to impute a value to replace the NULL values.
Rock Fragment Data
Rock fragments are particles larger than 2 mm. In SSURGO, fragment data are stored in several places both aggregated up to the horizon level, and in child tables of horizon.
Fragments are classified by size class (e.g. gravel, cobbles, stones, boulders) and recorded as volume percentages. Derived weight fractions are also stored at the horizon level.
Basic Rock Fragment Query
# Query horizons with their rock fragment content
q <- "
SELECT TOP 20
mu.musym,
co.compname,
ch.hzname,
ch.hzdept_r,
ch.hzdepb_r,
rf.fragkind,
rf.fragsize_h,
rf.fragvol_r
FROM legend AS leg
INNER JOIN mapunit AS mu ON mu.lkey = leg.lkey
INNER JOIN component AS co ON co.mukey = mu.mukey
LEFT JOIN chorizon AS ch ON ch.cokey = co.cokey
LEFT JOIN chfrags AS rf ON rf.chkey = ch.chkey
WHERE leg.areasymbol = 'CA630'
AND co.majcompflag = 'Yes'
ORDER BY mu.musym, co.comppct_r DESC, ch.hzdept_r, rf.fragsize_h
"
result <- SDA_query(q)
head(result, 20)## musym compname hzname hzdept_r hzdepb_r fragkind
## 1 1012 Mined land <NA> NA NA <NA>
## 2 1013 Mined land <NA> NA NA <NA>
## 3 1013 Anthraltic Xerorthents ^A 0 3 Mixed rock fragments
## 4 1013 Anthraltic Xerorthents ^A 0 3 Mixed rock fragments
## 5 1013 Anthraltic Xerorthents ^A 0 3 Mixed rock fragments
## 6 1013 Anthraltic Xerorthents ^AC 3 23 Mixed rock fragments
## 7 1013 Anthraltic Xerorthents ^AC 3 23 Mixed rock fragments
## 8 1013 Anthraltic Xerorthents ^AC 3 23 Mixed rock fragments
## 9 1013 Anthraltic Xerorthents ^C 23 100 Mixed rock fragments
## 10 1013 Anthraltic Xerorthents ^C 23 100 Mixed rock fragments
## 11 1013 Anthraltic Xerorthents ^C 23 100 Mixed rock fragments
## 12 1090 Ultic Haploxeralfs A 0 8 Mixed rock fragments
## 13 1090 Ultic Haploxeralfs BA 8 24 Mixed rock fragments
## 14 1090 Ultic Haploxeralfs BA 8 24 Mixed rock fragments
## 15 1090 Ultic Haploxeralfs BA 8 24 Mixed rock fragments
## 16 1090 Ultic Haploxeralfs Bt1 24 61 Mixed rock fragments
## 17 1090 Ultic Haploxeralfs Bt1 24 61 Mixed rock fragments
## 18 1090 Ultic Haploxeralfs Bt1 24 61 Mixed rock fragments
## 19 1090 Ultic Haploxeralfs Bt2 61 100 Mixed rock fragments
## 20 1090 Ultic Haploxeralfs Bt2 61 100 Mixed rock fragments
## fragsize_h fragvol_r
## 1 NA NA
## 2 NA NA
## 3 75 30
## 4 250 30
## 5 600 10
## 6 75 40
## 7 250 30
## 8 600 10
## 9 75 15
## 10 250 55
## 11 600 20
## 12 75 20
## 13 75 0
## 14 75 15
## 15 250 0
## 16 75 3
## 17 75 25
## 18 250 10
## 19 75 33
## 20 75 10Above you can see multiple fragment size classes can exist in a
single horizon (a many-to-one relationship). Horizons without fragments
generally have no records in the chfrags table.
chfragstable contains individual fragment records per horizon and size class (e.g. at least one each for gravel, cobbles, stones, boulders, where present)fragsize_hindicates upper end of fragment size range for a specific recordfragvol_ris the representative volume percentage for that specific record
Aggregating Rock Fragments by Horizon
Sum fragment volumes to get total rock fragment content per horizon:
# Total rock fragment content per horizon
q <- "
SELECT
mu.musym,
co.compname,
co.comppct_r,
ch.hzname,
ch.hzdept_r,
ch.hzdepb_r,
SUM(rf.fragvol_r) AS calc_fragvoltot_r,
COUNT(DISTINCT rf.fragsize_h) AS n_frag_classes
FROM legend AS leg
INNER JOIN mapunit AS mu ON mu.lkey = leg.lkey
INNER JOIN component AS co ON co.mukey = mu.mukey
LEFT JOIN chorizon AS ch ON ch.cokey = co.cokey
LEFT JOIN chfrags AS rf ON rf.chkey = ch.chkey
WHERE leg.areasymbol = 'CA630'
AND co.majcompflag = 'Yes'
GROUP BY mu.musym, co.compname, co.comppct_r, ch.hzname,
ch.hzdept_r, ch.hzdepb_r, ch.chkey
ORDER BY mu.musym, co.comppct_r DESC, ch.hzdept_r
"
result <- SDA_query(q)
head(result)## musym compname comppct_r hzname hzdept_r hzdepb_r
## 1 1012 Mined land 94 <NA> NA NA
## 2 1013 Mined land 70 <NA> NA NA
## 3 1013 Anthraltic Xerorthents 30 ^A 0 3
## 4 1013 Anthraltic Xerorthents 30 ^AC 3 23
## 5 1013 Anthraltic Xerorthents 30 ^C 23 100
## 6 1090 Ultic Haploxeralfs 60 A 0 8
## calc_fragvoltot_r n_frag_classes
## 1 NA 0
## 2 NA 0
## 3 70 3
## 4 80 3
## 5 90 3
## 6 20 1Note: T-SQL is strict about aggregation syntax. Every column in the SELECT clause that is not wrapped in an aggregate function (SUM, COUNT, etc.) MUST be listed in the GROUP BY clause.
Rock Fragment Properties via get_SDA_property()
Use get_SDA_property() to retrieve rock fragment
properties with aggregation:
# Get rock fragment weight percentages (3-10 inch class)
frag_3_10 <- get_SDA_property(
property = "Rock Fragments 3 - 10 inches - Rep Value", # equivalent to 'frag3to10_r'
method = "Dominant Component (Numeric)", # dominant component, weighted average by depth
areasymbols = "CA630",
top_depth = 0,
bottom_depth = 100 # depth range for averaging
)
head(frag_3_10)## mukey areasymbol musym
## 1 2403709 CA630 1012
## 2 2924914 CA630 1013
## 3 2924833 CA630 1090
## 4 2924834 CA630 1091
## 5 2924907 CA630 128
## 6 2924879 CA630 206
## muname
## 1 Mined land
## 2 Mined land-Anthraltic Xerorthents complex, 1 to 15 percent slopes
## 3 Ultic Haploxeralfs-Mollic Haploxeralfs complex, 3 to 30 percent slopes
## 4 Ultic Haploxeralfs-Aquic Dystroxerepts complex, 2 to 8 percent slopes
## 5 Cogna loam, 0 to 2 percent slopes, overwash
## 6 Pentz sandy loam, 2 to 15 percent slopes
## frag3to10_r
## 1 NA
## 2 54.39
## 3 13.00
## 4 7.24
## 5 0.00
## 6 3.00
# get fragment volume (fragvoltot_l, fragvoltot_r, fragvoltot_h)
fragvol_total <- get_SDA_property(
property = "fragvoltot_r",
method = "Weighted Average", # weighted by component percentage and depth
top_depth = 0,
bottom_depth = 100,
areasymbols = "CA630"
)
head(fragvol_total)## mukey areasymbol musym
## 1 2403709 CA630 1012
## 2 2924914 CA630 1013
## 3 2924833 CA630 1090
## 4 2924834 CA630 1091
## 5 2924907 CA630 128
## 6 2924879 CA630 206
## muname
## 1 Mined land
## 2 Mined land-Anthraltic Xerorthents complex, 1 to 15 percent slopes
## 3 Ultic Haploxeralfs-Mollic Haploxeralfs complex, 3 to 30 percent slopes
## 4 Ultic Haploxeralfs-Aquic Dystroxerepts complex, 2 to 8 percent slopes
## 5 Cogna loam, 0 to 2 percent slopes, overwash
## 6 Pentz sandy loam, 2 to 15 percent slopes
## fragvoltot_r
## 1 NA
## 2 87.40000
## 3 41.07137
## 4 43.15400
## 5 0.00000
## 6 14.00000Note: Fragment weight fraction properties in
chorizon (like frag3to10_r and
fraggt10_r) are always populated, but currently the
fragvoltot_* columns are not and data availability depends
on the vintage of the specific SSURGO map unit data.
SDA Query Limits and Strategies
SDA Query Limitations
The SDA system has important hard limits:
Record Limit: Queries that return more than 100,000 records are rejected
Result Size: Response serialization limited to approximately 32 Mb
Memory Limit: Queries generally cannot exceed approximately 300 Mb memory usage
Timeouts and Complexity: Long-running queries may timeout or hit other internal limits during query planning
Note on Local vs. Remote: These limits primarily
apply to the Remote SDA API. When querying a
local SQLite database (e.g. created via
createSSURGO() or downloadSSURGO()), you are
generally unrestricted by record counts or timeouts. Complex tabular
queries can often be run on entire states or the whole country locally
without the need for chunking or simplification.
Strategies for Large Queries
- Add WHERE clause to reduce result set:
# Bad: will return >100k records across all of SSURGO
q <- "SELECT * FROM component"
# Good: specific component name pattern in WHERE clause
q <- "SELECT * FROM component
WHERE compname LIKE 'Miami%'"- Use TOP clause to limit number of results (useful for testing):
# Test with small result set first
q <- "SELECT TOP 100 * FROM chorizon"
result <- SDA_query(q)TOP can be used after sorting with ORDER BY to easily
find the values associated with an ordered sequence. For instance, if
you ORDER BY comppct_r DESC (order by component percentage
in descending order), then take TOP 1 you will get the
records associated with the dominant component. This is a very common
aggregation scheme available as an option in most tools that use SSURGO
data.
TOP is also generally useful for testing queries, or checking table result structure for a few resulting rows. If testing is successful, remove TOP, add filtering with WHERE or in JOIN condition (see below), or increase the TOP limit.
- Aggregate and apply JOIN constraints early in the query:
Efficient queries often perform filtering operations as part of their JOIN statements. This can improve server-side query planning and reduce overhead that is not needed for the final result.
# Return aggregated results (fewer rows) instead of raw data
# and constrain musym in join to mapunit instead of WHERE
q <- "
SELECT mu.mukey,
COUNT(*) AS n_hz,
AVG(ch.claytotal_r) AS avg_clay
FROM component co
INNER JOIN mapunit mu ON mu.mukey = co.mukey AND mu.musym = '101'
INNER JOIN chorizon ch ON ch.cokey = co.cokey
GROUP BY mu.mukey
WHERE compname LIKE 'Musick%'
"- Explicitly select the columns you need:
Efficient queries also are explicit about columns in the SELECT clause.
While SELECT * is fine to use for testing, it is prone
to issues if schemas change, as well as returning more data than is
necessary in most cases.
# `SELECT *` will return all columns, usually including many columns you do not need
q <- "SELECT TOP 1 *
FROM mapunit
INNER JOIN component ON mapunit.mukey = component.mukey
WHERE compname LIKE 'Musick%'
"
# Use `SELECT column1, column2, ...` for concise results, with no duplicated columns in complex joins
q <- "
SELECT TOP 1 mapunit.mukey, musym, muname,
compname, localphase, comppct_r, majcompflag, compkind, cokey
FROM mapunit
INNER JOIN component ON mapunit.mukey = component.mukey
WHERE compname LIKE 'Musick%'
"If a column name occurs multiple times in different tables, you need
specify which one you want it to come from with
<tablename>.<columname> syntax.
If you do need all columns from a specific table use
<tablename>.* syntax, for example here we get all
columns from chfrags, and specific columns from
chorizon and component:
q <- "
SELECT hzname, chfrags.*, component.cokey
FROM chfrags
INNER JOIN chorizon ON chorizon.chkey = chfrags.chkey
INNER JOIN component ON component.cokey = chorizon.cokey
WHERE compname LIKE 'Musick%'
"-
Use
makeChunks()for large vectors (see next section)
makeChunks() is a helper function in the `soilDB``
package. It takes a vector of values as input, and assigns each value a
group (chunk) number. You can then calculate the unique chunk numbers
and iterate over them to process data in bite-sized pieces. This is
covered extensively in the next section.
SQL Dialect Handling
T-SQL Syntax Specifics
NULL Handling
# Check and filter for non-NULL - SDA uses IS NULL / IS NOT NULL
q <- "SELECT TOP 10 * FROM chorizon WHERE claytotal_r IS NOT NULL"
# Use ISNULL() to provide defaults e.g. convert missing clay content to 0
q <- "SELECT TOP 10 chkey, claytotal_r, ISNULL(claytotal_r, 0) AS clay FROM chorizon"Type Casting
# CAST for explicit type conversion
q <- "
SELECT TOP 10
claytotal_r,
CAST(claytotal_r AS INT) AS clay_int,
CAST(chkey AS CHAR(10)) AS chkey_str
FROM chorizon
WHERE claytotal_r != CAST(claytotal_r AS INT)
"Note: in example above, casting to INT is equivalent
to truncating the value by removing decimals, it does not follow the
rounding rules that R round() does, for example.
Query Chunking for Large Datasets
Why “Chunking”?
When you need data for many map units, components, soil survey areas, or other entities, a single query can exceed SDA’s limits.
SDA is a shared public resource, so it is generally encouraged to make requests that are as small and efficient as possible.
The makeChunks() function divides a large vector into
smaller chunks for iterative querying.
Before implementing any chunked query approach, you should also be
certain that your query can run properly on a small set, for example
just single chunk, or a result that is truncated using a
TOP clause.
Using makeChunks()
Suppose you have 5000 map unit keys to query. We can break that set
up into chunks of 1000 map units, and iterate over each chunk using
lapply()
large_mukey_list <- 461994:466995
# Divide into chunks of 1000
chunks <- soilDB::makeChunks(large_mukey_list, 1000)
# Now loop through chunks
results_list <- lapply(split(large_mukey_list, chunks), function(chunk_keys) {
# Build IN clause
in_clause <- soilDB::format_SQL_in_statement(chunk_keys)
# construct query
q <- sprintf(
"SELECT mukey, musym, muname FROM mapunit WHERE mukey IN %s", in_clause
)
cat(sprintf("Chunk mukey %d to %d\n", min(chunk_keys), max(chunk_keys)))
SDA_query(q)
})## Chunk mukey 461994 to 462993## Chunk mukey 462994 to 463993## Chunk mukey 463994 to 464993## Chunk mukey 464994 to 465993## Chunk mukey 465994 to 466993## Chunk mukey 466994 to 466995
# Combine results
all_results <- do.call(rbind, results_list)The above approach is readily converted to parallel processing, for
example using future::future.lapply(), or other custom
iterator functions that allow for progress reporting and other
diagnostics.
If you do choose to use parallel processing, you should limit the number of concurrent connections made to the API to a reasonable number, say, 2 to 5 requests at a time, with a maximum of about 10. You should also implement proper error handling and retry mechanisms (see Handling Errors section above).
Example Chunked Property Query
Here we query soil properties for 6 soil survey areas in chunks of 2.
test_areasymbols <- c("CA067", "CA077", "CA632", "CA644", "CA630", "CA649")
# Chunk into groups of 5
chunks <- soilDB::makeChunks(test_areasymbols, 2)
results_list <- lapply(split(test_areasymbols, chunks), function(chunk_keys) {
# Build IN clause
in_clause <- soilDB::format_SQL_in_statement(chunk_keys)
q <- sprintf("
SELECT
mu.mukey,
mu.musym,
mu.muname,
co.cokey,
co.compname,
SUM(hzdepb_r - hzdept_r) AS sum_hz_thickness
FROM legend AS leg
INNER JOIN mapunit AS mu ON mu.lkey = leg.lkey
INNER JOIN component AS co ON co.mukey = mu.mukey
INNER JOIN chorizon AS ch ON ch.cokey = co.cokey
WHERE leg.areasymbol IN %s
GROUP BY mu.mukey, mu.musym, mu.muname, co.cokey, co.compname
", in_clause)
cat(sprintf("Chunk %s completed\n", paste0(chunk_keys, collapse = ", ")))
SDA_query(q)
})## Chunk CA067, CA077 completed## Chunk CA632, CA644 completed## Chunk CA630, CA649 completed## mukey musym muname cokey
## 1.1 461845 101 Amador-Gillender complex, 2 to 15 percent slopes 26327297
## 1.2 461845 101 Amador-Gillender complex, 2 to 15 percent slopes 26327298
## 1.3 461845 101 Amador-Gillender complex, 2 to 15 percent slopes 26327299
## 1.4 461845 101 Amador-Gillender complex, 2 to 15 percent slopes 26327300
## 1.5 461845 101 Amador-Gillender complex, 2 to 15 percent slopes 26327301
## 1.6 461845 101 Amador-Gillender complex, 2 to 15 percent slopes 26327302
## compname sum_hz_thickness
## 1.1 Amador 73
## 1.2 Gillender 43
## 1.3 Jennylind 200
## 1.4 Peters 63
## 1.5 Pardee 200
## 1.6 Ranchoseco 200Note: The above sample query is not a good way to determine soil thickness, as it does not exclude thickness of non-soil layers (e.g. bedrock) that should not be counted as part of the soil depth. As an exercise, use the logic from the previous sections to improve this example to filter out bedrock.
Recommended Chunk Sizes
Typical queries: 1000-10000 items per chunk (safe for most queries)
Simple lookups: 10000-100000 items per chunk (less data per item)
Complex joins: 500-1000 items per chunk (more processing per item)
Monitor your query results and adjust based on SDA response times.
You may get an error:
Invalid query: The query processor ran out of internal resources and could not produce a query plan. This is a rare event and only expected for extremely complex queries or queries that reference a very large number of tables or partitions. Please simplify the query. If you believe you have received this message in error, contact Customer Support Services for more information.
If you see this, first confirm that your query syntax is correct for the result you are trying to obtain, for instance by trying it on a minimal small set of data. Critically evaluate the need for joins, subqueries, and complex filtering logic. Identify any areas of repeated logic and refactor to simplify redundant steps. If your query works as expected on a small data set, and you have optimized it, then consider breaking your big query up into (more) chunks.
get_SDA_property(): Component and Horizon
Properties
The get_SDA_property() function queries the “SSURGO On
Demand” service to retrieve soil component and horizon properties with
automatic aggregation to the map unit level.
By default get_SDA_property() includes minor components
(include_minors=TRUE) but excludes miscellaneous areas
miscellaneous_areas=FALSE. Even miscellaneous areas that
have some soil data are excluded.
Available Properties
SDA has 80+ horizon properties and 40+ component properties.
Here are some common examples.
Component properties:
-
"Taxonomic Order","Taxonomic Suborder","Taxonomic Temperature Regime" -
"Drainage Class","Hydrologic Group" -
"Corrosion of Steel","Corrosion of Concrete" "Range Production - Favorable/Normal/Unfavorable Year"
Horizon properties:
Water:
"Available Water Capacity - Rep Value","0.1 bar H2O - Rep Value","0.33 bar H2O - Rep Value","15 bar H2O - Rep Value"Bulk Density:
"Bulk Density 0.1 bar H2O - Rep Value","Bulk Density 0.33 bar H2O - Rep Value","Bulk Density 15 bar H2O - Rep Value","Bulk Density oven dry - Rep Value"Texture:
"Total Sand - Rep Value","Total Silt - Rep Value","Total Clay - Rep Value", and sand/silt sub-fractionsChemistry:
"pH 1:1 water - Rep Value","Electrical Conductivity - Rep Value","Cation Exchange Capacity - Rep Value","Sodium Adsorption Ratio - Rep Value","Calcium Carbonate - Rep Value","Gypsum - Rep Value"Other:
"Saturated Hydraulic Conductivity - Rep Value","Organic Matter - Rep Value","Free Iron - Rep Value","Oxalate Iron - Rep Value"
Alternately, you can directly use physical column names from the
SSURGO schema like "claytotal_r",
"ph1to1h2o_r", "ksat_r", etc.
Method: Dominant Component (Category)
Dominant component (category) get the categorical value from the dominant soil component. This query is a distinct method as categorical data need to be handled differently from numeric data; the numeric method is described below.
# Get taxonomic classification from dominant component
tax_order <- get_SDA_property(
property = "Taxonomic Suborder",
method = "Dominant Component (Category)",
areasymbols = "CA630"
)
head(tax_order)## mukey areasymbol musym muname
## 1 2924907 CA630 128 Cogna loam, 0 to 2 percent slopes, overwash
## 2 2924879 CA630 206 Pentz sandy loam, 2 to 15 percent slopes
## 3 2924880 CA630 207 Pentz sandy loam, 15 to 50 percent slopes
## 4 2924881 CA630 208 Pentz cobbly sandy loam, 2 to 8 percent slopes
## 5 2924882 CA630 209 Pentz-Bellota complex, 2 to 15 percent slopes
## 6 2924883 CA630 212 Peters clay, 2 to 8 percent slopes
## taxsuborder
## 1 Xerolls
## 2 Xerolls
## 3 Xerolls
## 4 Xerolls
## 5 Xerolls
## 6 XerollsMethod: Dominant Component (Numeric)
Dominant component (numeric) retrieves properties from the dominant component, optionally averaged over a depth range (in centimeters):
# Get bulk density at 0-25 cm depth
bulk_density <- get_SDA_property(
property = c("dbthirdbar_l", "dbthirdbar_r", "dbthirdbar_h"),
method = "Dominant Component (Numeric)",
areasymbols = "CA630",
top_depth = 0,
bottom_depth = 25
)
head(bulk_density)## mukey areasymbol musym
## 1 2403709 CA630 1012
## 2 2924914 CA630 1013
## 3 2924833 CA630 1090
## 4 2924834 CA630 1091
## 5 2924907 CA630 128
## 6 2924879 CA630 206
## muname
## 1 Mined land
## 2 Mined land-Anthraltic Xerorthents complex, 1 to 15 percent slopes
## 3 Ultic Haploxeralfs-Mollic Haploxeralfs complex, 3 to 30 percent slopes
## 4 Ultic Haploxeralfs-Aquic Dystroxerepts complex, 2 to 8 percent slopes
## 5 Cogna loam, 0 to 2 percent slopes, overwash
## 6 Pentz sandy loam, 2 to 15 percent slopes
## dbthirdbar_l dbthirdbar_r dbthirdbar_h
## 1 NA NA NA
## 2 1.5028 1.5416 1.5792
## 3 1.3288 1.4504 1.5724
## 4 1.4468 1.5216 1.5964
## 5 1.4300 1.4800 1.5400
## 6 1.3760 1.4800 1.5820Method: Weighted Average
The weighted average method retrieves component percentage and
depth-weighted average across all components in a map unit. In this
example we explicitly exclude minor components by changing the default
include_minors argument.
# Get weighted average clay content (0-50 cm)
clay_avg <- get_SDA_property(
property = "Total Clay - Rep Value",
method = "Weighted Average",
areasymbols = "CA630",
top_depth = 0,
bottom_depth = 50,
include_minors = FALSE
)
head(clay_avg)## mukey areasymbol musym
## 1 2403709 CA630 1012
## 2 2924914 CA630 1013
## 3 2924833 CA630 1090
## 4 2924834 CA630 1091
## 5 2924907 CA630 128
## 6 2924879 CA630 206
## muname
## 1 Mined land
## 2 Mined land-Anthraltic Xerorthents complex, 1 to 15 percent slopes
## 3 Ultic Haploxeralfs-Mollic Haploxeralfs complex, 3 to 30 percent slopes
## 4 Ultic Haploxeralfs-Aquic Dystroxerepts complex, 2 to 8 percent slopes
## 5 Cogna loam, 0 to 2 percent slopes, overwash
## 6 Pentz sandy loam, 2 to 15 percent slopes
## claytotal_r
## 1 NA
## 2 2.58000
## 3 18.02000
## 4 20.40400
## 5 13.00000
## 6 14.47368Method: Min/Max
Method `“Min/Max” is used to get minimum or maximum values across all components in a mapunit.
# Get maximum sand content in any component
sand_max <- get_SDA_property(
property = "Total Sand - Rep Value",
method = "Min/Max",
areasymbols = "CA630",
FUN = "MAX",
top_depth = 0,
bottom_depth = 50
)
head(sand_max)## mukey areasymbol musym
## 1 1865918 CA630 3046
## 2 1865926 CA630 7088
## 3 1865927 CA630 7155
## 4 1865928 CA630 7156
## 5 1865929 CA630 8033
## 6 1865930 CA630 8034
## muname sandtotal_r
## 1 Goldwall-Toomes-Rock outcrop complex, 1 to 8 percent slopes 55
## 2 Loafercreek-Gopheridge complex, 30 to 60 percent slopes 50
## 3 Crimeahouse-Sixbit complex, 3 to 15 percent slopes 51
## 4 Crimeahouse-Sixbit complex, 15 to 30 percent slopes 58
## 5 Copperopolis-Whiterock complex, 2 to 8 percent slopes, rocky 45
## 6 Copperopolis-Whiterock complex, 3 to 15 percent slopes, rocky 45Method: Dominant Condition
Dominant condition aggregates components with the same category value for the properties of interest, then picks the dominant percentage. This gives extra weight to categories where multiple soils in the same map unit have the same value.
# Get dominant drainage class condition
drain_dominant <- get_SDA_property(
property = "Drainage Class",
method = "Dominant Condition",
areasymbols = "CA630"
)
head(drain_dominant)## mukey areasymbol musym
## 1 1865918 CA630 3046
## 2 1865926 CA630 7088
## 3 1865927 CA630 7155
## 4 1865928 CA630 7156
## 5 1865929 CA630 8033
## 6 1865930 CA630 8034
## muname
## 1 Goldwall-Toomes-Rock outcrop complex, 1 to 8 percent slopes
## 2 Loafercreek-Gopheridge complex, 30 to 60 percent slopes
## 3 Crimeahouse-Sixbit complex, 3 to 15 percent slopes
## 4 Crimeahouse-Sixbit complex, 15 to 30 percent slopes
## 5 Copperopolis-Whiterock complex, 2 to 8 percent slopes, rocky
## 6 Copperopolis-Whiterock complex, 3 to 15 percent slopes, rocky
## drainagecl
## 1 Moderately well drained
## 2 Well drained
## 3 Well drained
## 4 Well drained
## 5 Well drained
## 6 Well drainedMethod: None
Method "none" returns one row per component or component
horizon, depending on the property selected, with no map unit
aggregation. This generally returns much more data, but allows for
custom aggregation outside of the SQL query, and deeper inspection of
the source data.
You cannot mix component-level and horizon-level properties with this
method. Run it twice, once for horizon-level and once for
component-level, then join the component data to the horizon data using
the cokey column to get a single data frame.
Also, the top_depth and bottom_depth
arguments are deliberately ignored with this method. Apply your own
filtering to the result if you only need a specific depth range.
# Get all pH values by component and horizon
ph_all <- get_SDA_property(
property = "pH 1:1 water - Rep Value",
method = "None",
areasymbols = "CA630"
)
head(ph_all)## mukey cokey areasymbol musym
## 1 1865918 26411696 CA630 3046
## 2 1865918 26411696 CA630 3046
## 3 1865918 26411695 CA630 3046
## 4 1865918 26411695 CA630 3046
## 5 1865918 26411695 CA630 3046
## 6 1865918 26411698 CA630 3046
## muname compname
## 1 Goldwall-Toomes-Rock outcrop complex, 1 to 8 percent slopes Goldwall
## 2 Goldwall-Toomes-Rock outcrop complex, 1 to 8 percent slopes Goldwall
## 3 Goldwall-Toomes-Rock outcrop complex, 1 to 8 percent slopes Toomes
## 4 Goldwall-Toomes-Rock outcrop complex, 1 to 8 percent slopes Toomes
## 5 Goldwall-Toomes-Rock outcrop complex, 1 to 8 percent slopes Toomes
## 6 Goldwall-Toomes-Rock outcrop complex, 1 to 8 percent slopes Ultic Argixerolls
## compkind comppct_r majcompflag chkey hzdept_r hzdepb_r
## 1 Series 45 Yes 78806274 0 15
## 2 Series 45 Yes 78806273 15 200
## 3 Series 28 Yes 78806272 0 2
## 4 Series 28 Yes 78806271 2 33
## 5 Series 28 Yes 78806270 33 200
## 6 Taxon above family 5 No 78806281 0 25
## ph1to1h2o_r
## 1 5.5
## 2 NA
## 3 5.2
## 4 5.5
## 5 NA
## 6 6.0Inspecting Generated Queries
We can use query_string = TRUE to see the SQL generated
by get_SDA_property():
q <- get_SDA_property(
property = "Taxonomic Suborder",
method = "Dominant Component (Category)",
areasymbols = "CA630",
query_string = TRUE
)
# View first 500 characters of query
cat(substr(q, 1, 500), "...\n")## SELECT mapunit.mukey, areasymbol, musym, muname, taxsuborder AS taxsuborder
## FROM legend
## INNER JOIN mapunit ON mapunit.lkey = legend.lkey AND legend.areasymbol IN ('CA630')
## INNER JOIN component ON component.mukey = mapunit.mukey AND
## component.cokey = (SELECT TOP 1 c1.cokey FROM component AS c1
## INNER JOIN mapunit AS mu ON component.mukey = mu.mukey AND
## ...
get_SDA_interpretation(): Soil Interpretations
Soil interpretations are ratings that assess how suitable or limited
a soil is for various land uses. An interpretation for a specific
component or map unit includes a rating class, and a numeric value
(“fuzzy rating”). The get_SDA_interpretation() function
retrieves these ratings with multiple aggregation methods.
Available Interpretations
SDA contains 600+ interpretations organized by category:
| Category | Examples |
|---|---|
FOR (Forestry) |
Potential Seedling Mortality, Road Suitability, Harvest Suitability, Equipment Operability |
AGR (Agriculture) |
Crop Yield, Irrigation Suitability, Pesticide Pollution Potential |
ENG (Engineering) |
Septic Tank Absorption Fields, Construction Roads, Dwelling Foundations, Dam Sites |
URB/REC (Urban/Recreation) |
Trails, Playgrounds, Picnic Areas, Recreational Development |
AWM (Animal Waste Management) |
Wastewater Application Sites, Manure Storage |
WMS (Water Management System) |
Irrigation Suitability, Drainage, Wetland Rating |
CPI (Commodity Crop Productivity Index) |
National Commodity Crop Productivity Index |
Method: Dominant Component
Get the rating from the dominant soil component:
# Get forestry ratings for dominant component
for_ratings <- get_SDA_interpretation(
rulename = c("FOR - Potential Seedling Mortality",
"FOR - Road Suitability (Natural Surface)"),
method = "Dominant Component",
areasymbols = "CA630"
)
head(for_ratings)## mukey cokey areasymbol musym
## 1 2924907 26412202 CA630 128
## 2 2924879 26412137 CA630 206
## 3 2924880 26412145 CA630 207
## 4 2924881 26412157 CA630 208
## 5 2924882 26412161 CA630 209
## 6 2924883 26412164 CA630 212
## muname compname compkind comppct_r
## 1 Cogna loam, 0 to 2 percent slopes, overwash Cogna Series 85
## 2 Pentz sandy loam, 2 to 15 percent slopes Pentz Series 85
## 3 Pentz sandy loam, 15 to 50 percent slopes Pentz Series 85
## 4 Pentz cobbly sandy loam, 2 to 8 percent slopes Pentz Series 85
## 5 Pentz-Bellota complex, 2 to 15 percent slopes Pentz Series 55
## 6 Peters clay, 2 to 8 percent slopes Peters Series 85
## majcompflag rating_FORPotentialSeedlingMortality
## 1 Yes 0.660
## 2 Yes 0.903
## 3 Yes 0.935
## 4 Yes 0.977
## 5 Yes 0.929
## 6 Yes 0.845
## class_FORPotentialSeedlingMortality
## 1 Moderate
## 2 Moderate
## 3 Moderate
## 4 Moderate
## 5 Moderate
## 6 Moderate
## reason_FORPotentialSeedlingMortality
## 1 FOR - Available Water Limitation "Moderately low moisture supply" (0.66)
## 2 FOR - Available Water Limitation "Moisture supply low" (0.903)
## 3 FOR - Available Water Limitation "Moisture supply low" (0.935)
## 4 FOR - Available Water Limitation "Moisture supply low" (0.977)
## 5 FOR - Available Water Limitation "Moisture supply low" (0.929)
## 6 FOR - Available Water Limitation "Moisture supply low" (0.845)
## rating_FORRoadSuitabilityNaturalSurface
## 1 0.039
## 2 0.763
## 3 1.000
## 4 0.080
## 5 0.215
## 6 1.000
## class_FORRoadSuitabilityNaturalSurface
## 1 Well suited
## 2 Moderately suited
## 3 Poorly suited
## 4 Well suited
## 5 Well suited
## 6 Poorly suited
## reason_FORRoadSuitabilityNaturalSurface
## 1 FOR - Strength Limitation (2) "Low strength" (0.039)
## 2 FOR - Slope Limitation (<6% to >12%) "Slope" (0.763)
## 3 FOR - Slope Limitation (<6% to >12%) "Slope" (1)
## 4 FOR - Rock Fragments Limitation (1) "Rock fragments" (0.08); FOR - Slope Limitation (<6% to >12%) "Slope" (0.054)
## 5 FOR - Slope Limitation (<6% to >12%) "Slope" (0.215); FOR - Strength Limitation (2) "Low strength" (0.055)
## 6 FOR - Strength Limitation (2) "Low strength" (1); FOR - Stickiness Limitation (1) "Stickiness; high plasticity index" (0.5)Method: Dominant Condition
Aggregate similar ratings, then return the dominant:
# Get dominant engineering interpretation
eng_ratings <- get_SDA_interpretation(
rulename = "ENG - Septic Tank Absorption Fields",
method = "Dominant Condition",
areasymbols = "CA649"
)
head(eng_ratings)## mukey areasymbol musym
## 1 463229 CA649 AaC
## 2 463230 CA649 AaD
## 3 463231 CA649 AbE
## 4 463232 CA649 AcE
## 5 463233 CA649 AdG
## 6 463234 CA649 AeD
## muname
## 1 Ahwahnee sandy loam, 2 to 9 percent slopes
## 2 Ahwahnee sandy loam, 9 to 15 percent slopes
## 3 Ahwahnee-Auberry sandy loams, 15 to 30 percent slopes
## 4 Ahwahnee-Auberry rocky sandy loams, 9 to 30 percent slopes
## 5 Ahwahnee-Auberry very rocky sandy loams, 30 to 75 percent slope
## 6 Auberry sandy loam, 9 to 15 percent slopes
## rating_ENGSepticTankAbsorptionFields
## 1 1
## 2 1
## 3 1
## 4 1
## 5 1
## 6 1
## total_comppct_ENGSepticTankAbsorptionFields
## 1 85
## 2 85
## 3 90
## 4 90
## 5 88
## 6 85
## class_ENGSepticTankAbsorptionFields
## 1 Very limited
## 2 Very limited
## 3 Very limited
## 4 Very limited
## 5 Very limited
## 6 Very limited
## reason_ENGSepticTankAbsorptionFields
## 1 Shallow to Bedrock 100 - 180cm "Depth to bedrock" (1); Seepage Bottom Layer, Not Aridic "Seepage, bottom layer" (1)
## 2 Shallow to Bedrock 100 - 180cm "Depth to bedrock" (1); Seepage Bottom Layer, Not Aridic "Seepage, bottom layer" (1); Slope 8 to > 15% "Slope" (0.633)
## 3 Slope 8 to > 15% "Slope" (1); Shallow to Bedrock 100 - 180cm "Depth to bedrock" (1); Seepage Bottom Layer, Not Aridic "Seepage, bottom layer" (1)
## 4 Shallow to Bedrock 100 - 180cm "Depth to bedrock" (1); Slope 8 to > 15% "Slope" (1); Seepage Bottom Layer, Not Aridic "Seepage, bottom layer" (1)
## 5 Slope 8 to > 15% "Slope" (1); Shallow to Bedrock 100 - 180cm "Depth to bedrock" (1); Seepage Bottom Layer, Not Aridic "Seepage, bottom layer" (1)
## 6 Shallow to Bedrock 100 - 180cm "Depth to bedrock" (1); Slope 8 to > 15% "Slope" (0.633); Percolation 60 - 180cm (24-72") "Slow water movement" (0.498)Method: Weighted Average
Component-percentage-weighted average of ratings:
# Get weighted average agricultural rating
agr_weighted <- get_SDA_interpretation(
rulename = "AGR - Winter Wheat Yield (MT)",
method = "Weighted Average",
areasymbols = "MT041",
include_minors = TRUE
)
head(agr_weighted)## areasymbol musym muname mukey
## 1 MT041 13A McKenzie clay, 0 to 1 percent slopes 343852
## 2 MT041 16B Degrand loam, 0 to 4 percent slopes 343858
## 3 MT041 22E Hillon-Joplin loams, 8 to 25 percent slopes 343880
## 4 MT041 22F Hillon loam, 15 to 60 percent slopes 343881
## 5 MT041 24A Hanly loamy fine sand, 0 to 2 percent slopes 343883
## 6 MT041 27B Attewan loam, 0 to 4 percent slopes 343891
## rating_AGRWinterWheatYieldMT class_AGRWinterWheatYieldMT
## 1 0.02 <NA>
## 2 0.25 <NA>
## 3 0.26 <NA>
## 4 0.05 <NA>
## 5 0.22 <NA>
## 6 0.25 <NA>
## reason_AGRWinterWheatYieldMT
## 1 -UNKNOWN- (0.301); -UNKNOWN- (0.107); -UNKNOWN- (0.107); -UNKNOWN- (0.107); -UNKNOWN- (0.041); -UNKNOWN- (0.107); -UNKNOWN- (0.107)
## 2 -UNKNOWN- (0.206); -UNKNOWN- (0.107); -UNKNOWN- (0.238); -UNKNOWN- (0.107); -UNKNOWN- (0.256); -UNKNOWN- (0.107); -UNKNOWN- (0.219); -UNKNOWN- (0.107); -UNKNOWN- (0.205); -UNKNOWN- (0.107)
## 3 -UNKNOWN- (0.281); -UNKNOWN- (0.107); -UNKNOWN- (0.223); -UNKNOWN- (0.107); -UNKNOWN- (0.27); -UNKNOWN- (0.107); -UNKNOWN- (0.237); -UNKNOWN- (0.107); -UNKNOWN- (0.107); -UNKNOWN- (0.098); -UNKNOWN- (0.197); -UNKNOWN- (0.107); -UNKNOWN- (0.231); -UNKNOWN- (0.107)
## 4 -UNKNOWN- (0.231); -UNKNOWN- (0.107); -UNKNOWN- (0.107); -UNKNOWN- (0.188); -UNKNOWN- (0.107); -UNKNOWN- (0.281); -UNKNOWN- (0.107); -UNKNOWN- (0.107); -UNKNOWN- (0.223); -UNKNOWN- (0.107); -UNKNOWN- (0.107)
## 5 -UNKNOWN- (0.234); -UNKNOWN- (0.107); -UNKNOWN- (0.196); -UNKNOWN- (0.107); -UNKNOWN- (0.164); -UNKNOWN- (0.107); -UNKNOWN- (0.196); -UNKNOWN- (0.107); -UNKNOWN- (0.196); -UNKNOWN- (0.107)
## 6 -UNKNOWN- (0.133); -UNKNOWN- (0.107); -UNKNOWN- (0.164); -UNKNOWN- (0.107); -UNKNOWN- (0.107); -UNKNOWN- (0.219); -UNKNOWN- (0.107); -UNKNOWN- (0.219); -UNKNOWN- (0.107)Note: in this example, a regional (Montana-specific) interpretation is used, so we used a Montana areasymbol (MT041). Some interpretations are only exported for specific states, regions, or soil survey areas.
Method: None
Return one row per component with no map unit aggregation:
# Get all component-level ratings
all_ratings <- get_SDA_interpretation(
rulename = "FOR - Mechanical Planting Suitability",
method = "None",
areasymbols = "CA630"
)
head(all_ratings)## mukey cokey areasymbol musym muname
## 1 2924907 26412197 CA630 128 Cogna loam, 0 to 2 percent slopes, overwash
## 2 2924907 26412198 CA630 128 Cogna loam, 0 to 2 percent slopes, overwash
## 3 2924907 26412199 CA630 128 Cogna loam, 0 to 2 percent slopes, overwash
## 4 2924907 26412200 CA630 128 Cogna loam, 0 to 2 percent slopes, overwash
## 5 2924907 26412201 CA630 128 Cogna loam, 0 to 2 percent slopes, overwash
## 6 2924907 26412202 CA630 128 Cogna loam, 0 to 2 percent slopes, overwash
## compname compkind comppct_r majcompflag
## 1 Columbia Series 1 No
## 2 Veritas Series 3 No
## 3 Archerdale Series 6 No
## 4 Nord Taxadjunct 4 No
## 5 Honcut Series 1 No
## 6 Cogna Series 85 Yes
## rating_FORMechanicalPlantingSuitability
## 1 0.00
## 2 0.00
## 3 0.75
## 4 0.00
## 5 0.00
## 6 0.00
## class_FORMechanicalPlantingSuitability
## 1 Well suited
## 2 Well suited
## 3 Poorly suited
## 4 Well suited
## 5 Well suited
## 6 Well suited
## reason_FORMechanicalPlantingSuitability
## 1 <NA>
## 2 <NA>
## 3 Stickiness Limitation (4) (Updated) "Stickiness; high plasticity index" (0.75); Rock Fragments Limitation (5) (Updated) "Rock fragments" (0.55)
## 4 <NA>
## 5 <NA>
## 6 <NA>Understanding Output Columns
Use wide_reason = TRUE to pivot reason columns into
separate sub-rule columns:
# Get detailed ratings with reasons pivoted
detailed <- get_SDA_interpretation(
rulename = "FOR - Mechanical Planting Suitability",
method = "Dominant Component",
areasymbols = "CA630",
wide_reason = TRUE
)
head(detailed)## mukey cokey areasymbol musym
## 1 2924907 26412202 CA630 128
## 2 2924879 26412137 CA630 206
## 3 2924880 26412145 CA630 207
## 4 2924881 26412157 CA630 208
## 5 2924882 26412161 CA630 209
## 6 2924883 26412164 CA630 212
## muname compname compkind comppct_r
## 1 Cogna loam, 0 to 2 percent slopes, overwash Cogna Series 85
## 2 Pentz sandy loam, 2 to 15 percent slopes Pentz Series 85
## 3 Pentz sandy loam, 15 to 50 percent slopes Pentz Series 85
## 4 Pentz cobbly sandy loam, 2 to 8 percent slopes Pentz Series 85
## 5 Pentz-Bellota complex, 2 to 15 percent slopes Pentz Series 55
## 6 Peters clay, 2 to 8 percent slopes Peters Series 85
## majcompflag rating_FORMechanicalPlantingSuitability
## 1 Yes 0.000
## 2 Yes 0.620
## 3 Yes 0.987
## 4 Yes 1.000
## 5 Yes 0.620
## 6 Yes 0.750
## class_FORMechanicalPlantingSuitability
## 1 Well suited
## 2 Poorly suited
## 3 Unsuited
## 4 Unsuited
## 5 Poorly suited
## 6 Poorly suited
## reason_FORMechanicalPlantingSuitability
## 1 <NA>
## 2 Rock Fragments Limitation (5) (Updated) "Rock fragments" (0.62); Slope Limitation (<5% to >35%) "Slope" (0.4)
## 3 Slope Limitation (<5% to >35%) "Slope" (0.987); Rock Fragments Limitation (5) (Updated) "Rock fragments" (0.62)
## 4 Rock Fragments Limitation (5) (Updated) "Rock fragments" (1); Slope Limitation (<5% to >35%) "Slope" (0.112)
## 5 Rock Fragments Limitation (5) (Updated) "Rock fragments" (0.62); Slope Limitation (<5% to >35%) "Slope" (0.203)
## 6 Stickiness Limitation (4) (Updated) "Stickiness; high plasticity index" (0.75); Slope Limitation (<5% to >35%) "Slope" (0.002)
## rating_reason_FORMechanicalPlantingSuitability_Notrated
## 1 NA
## 2 NA
## 3 NA
## 4 NA
## 5 NA
## 6 NA
## rating_reason_FORMechanicalPlantingSuitability_RockFragmentsLimitation5Updated
## 1 <NA>
## 2 0.62
## 3 0.62
## 4 1
## 5 0.62
## 6 <NA>
## rating_reason_FORMechanicalPlantingSuitability_SlopeLimitationLT5toGT35
## 1 <NA>
## 2 0.4
## 3 0.987
## 4 0.112
## 5 0.203
## 6 0.002
## rating_reason_FORMechanicalPlantingSuitability_StickinessLimitation4UpdatedStickiness
## 1 <NA>
## 2 <NA>
## 3 <NA>
## 4 <NA>
## 5 <NA>
## 6 <NA>
## rating_reason_FORMechanicalPlantingSuitability_highplasticityindex075
## 1 <NA>
## 2 <NA>
## 3 <NA>
## 4 <NA>
## 5 <NA>
## 6 <NA>
## rating_reason_FORMechanicalPlantingSuitability_SandLimitation3Updated
## 1 <NA>
## 2 <NA>
## 3 <NA>
## 4 <NA>
## 5 <NA>
## 6 <NA>
## rating_reason_FORMechanicalPlantingSuitability_ComponentKindMiscandCHIIDisnull
## 1 <NA>
## 2 <NA>
## 3 <NA>
## 4 <NA>
## 5 <NA>
## 6 <NA>
## rating_reason_FORMechanicalPlantingSuitability_NullHorizonData
## 1 <NA>
## 2 <NA>
## 3 <NA>
## 4 <NA>
## 5 <NA>
## 6 <NA>
## rating_reason_FORMechanicalPlantingSuitability_RestrictiveLayerLimitation2Updated
## 1 <NA>
## 2 <NA>
## 3 <NA>
## 4 <NA>
## 5 <NA>
## 6 <NA>
## rating_reason_FORMechanicalPlantingSuitability_highplasticityindex008
## 1 <NA>
## 2 <NA>
## 3 <NA>
## 4 <NA>
## 5 <NA>
## 6 <NA>
## rating_reason_FORMechanicalPlantingSuitability_highplasticityindex0224
## 1 <NA>
## 2 <NA>
## 3 <NA>
## 4 <NA>
## 5 <NA>
## 6 <NA>
## rating_reason_FORMechanicalPlantingSuitability_highplasticityindex0154
## 1 <NA>
## 2 <NA>
## 3 <NA>
## 4 <NA>
## 5 <NA>
## 6 <NA>
## rating_reason_FORMechanicalPlantingSuitability_highplasticityindex0358
## 1 <NA>
## 2 <NA>
## 3 <NA>
## 4 <NA>
## 5 <NA>
## 6 <NA>
get_SDA_hydric(): Hydric Soil Classifications
Hydric soils are inundated or saturated long enough during the
growing season to develop anaerobic conditions. The
get_SDA_hydric() function evaluates the proportion of
hydric components in a map unit.
Method: MAPUNIT (Default)
Returns an overall classification for each map unit:
hydric_class <- get_SDA_hydric(
areasymbols = c("CA077", "CA630"),
method = "MAPUNIT"
)
head(hydric_class)## mukey areasymbol musym
## 1 461993 CA077 101
## 2 461994 CA077 102
## 3 461995 CA077 103
## 4 461996 CA077 104
## 5 461998 CA077 106
## 6 461999 CA077 107
## muname
## 1 Acampo sandy loam, 0 to 2 percent slopes
## 2 Alamo clay, 0 to 2 percent slopes
## 3 Alo-Vaquero complex, 8 to 30 percent slopes, MLRA 15
## 4 Alo-Vaquero complex, 30 to 50 percent slopes, MLRA 15
## 5 Archerdale very fine sandy loam, 0 to 2 percent slopes, overwashed
## 6 Archerdale clay loam, 0 to 2 percent slopes
## total_comppct hydric_majors hydric_inclusions HYDRIC_RATING
## 1 100 0 4 Predominantly Nonhydric
## 2 100 85 8 Predominantly Hydric
## 3 100 0 0 Nonhydric
## 4 100 0 0 Nonhydric
## 5 100 0 4 Predominantly Nonhydric
## 6 100 0 0 Nonhydric
# Check unique ratings
unique(hydric_class$HYDRIC_RATING)## [1] "Predominantly Nonhydric" "Predominantly Hydric"
## [3] "Nonhydric" "Hydric"
## [5] "Partially Hydric"Possible classifications:
"Nonhydric"- No hydric components"Hydric"- All major components are hydric"Predominantly Hydric"- Hydric components >= 50%"Partially Hydric"- One or more major components are hydric"Predominantly Nonhydric"- Hydric components < 50%
The output includes:
hydric_majors- Percentage of hydric major componentshydric_inclusions- Percentage of hydric minor/inclusion componentstotal_comppct- Total component percentage (should sum to 100)
Method: DOMINANT COMPONENT
Get hydric status of the dominant component only:
hydric_dom <- get_SDA_hydric(
areasymbols = "CA630",
method = "DOMINANT COMPONENT"
)
head(hydric_dom)## areasymbol musym muname mukey
## 1 CA630 128 Cogna loam, 0 to 2 percent slopes, overwash 2924907
## 2 CA630 206 Pentz sandy loam, 2 to 15 percent slopes 2924879
## 3 CA630 207 Pentz sandy loam, 15 to 50 percent slopes 2924880
## 4 CA630 208 Pentz cobbly sandy loam, 2 to 8 percent slopes 2924881
## 5 CA630 209 Pentz-Bellota complex, 2 to 15 percent slopes 2924882
## 6 CA630 212 Peters clay, 2 to 8 percent slopes 2924883
## cokey compname compkind comppct_r majcompflag hydricrating
## 1 26412202 Cogna Series 85 Yes No
## 2 26412137 Pentz Series 85 Yes No
## 3 26412145 Pentz Series 85 Yes No
## 4 26412157 Pentz Series 85 Yes No
## 5 26412161 Pentz Series 55 Yes No
## 6 26412164 Peters Series 85 Yes NoMethod: DOMINANT CONDITION
Aggregate by hydric condition (Yes/No), then pick the dominant:
hydric_cond <- get_SDA_hydric(
mukeys = c(461994, 461995, 462205),
method = "DOMINANT CONDITION"
)
head(hydric_cond)## areasymbol musym
## 1 CA077 102
## 2 CA077 103
## 3 CA624 AzE
## muname mukey
## 1 Alamo clay, 0 to 2 percent slopes 461994
## 2 Alo-Vaquero complex, 8 to 30 percent slopes, MLRA 15 461995
## 3 Auburn cobbly clay loam, heavy subsoil variant, 9 to 50 percent slopes 462205
## hydricrating
## 1 Yes
## 2 No
## 3 NoMethod: NONE
Return one row per component (component-level hydric status):
hydric_all <- get_SDA_hydric(
areasymbols = "CA630",
method = "NONE"
)
head(hydric_all)## areasymbol musym muname mukey cokey
## 1 CA630 128 Cogna loam, 0 to 2 percent slopes, overwash 2924907 26412197
## 2 CA630 128 Cogna loam, 0 to 2 percent slopes, overwash 2924907 26412198
## 3 CA630 128 Cogna loam, 0 to 2 percent slopes, overwash 2924907 26412199
## 4 CA630 128 Cogna loam, 0 to 2 percent slopes, overwash 2924907 26412200
## 5 CA630 128 Cogna loam, 0 to 2 percent slopes, overwash 2924907 26412201
## 6 CA630 128 Cogna loam, 0 to 2 percent slopes, overwash 2924907 26412202
## compname compkind comppct_r majcompflag hydricrating
## 1 Columbia Series 1 No No
## 2 Veritas Series 3 No No
## 3 Archerdale Series 6 No No
## 4 Nord Taxadjunct 4 No No
## 5 Honcut Series 1 No No
## 6 Cogna Series 85 Yes No
get_SDA_muaggatt(): Map Unit Aggregate Attributes
Map unit aggregate attributes are pre-computed statistics summarizing the components in a map unit. These include surface texture, slope range, permeability, and other physical properties.
muagg <- get_SDA_muaggatt(
areasymbols = "CA630"
)
head(muagg)## mukey musym muname mustatus
## 1 2924907 128 Cogna loam, 0 to 2 percent slopes, overwash <NA>
## 2 2924879 206 Pentz sandy loam, 2 to 15 percent slopes <NA>
## 3 2924880 207 Pentz sandy loam, 15 to 50 percent slopes <NA>
## 4 2924881 208 Pentz cobbly sandy loam, 2 to 8 percent slopes <NA>
## 5 2924882 209 Pentz-Bellota complex, 2 to 15 percent slopes <NA>
## 6 2924883 212 Peters clay, 2 to 8 percent slopes <NA>
## slopegraddcp slopegradwta brockdepmin wtdepannmin wtdepaprjunmin flodfreqdcd
## 1 1 1.0 NA NA NA Rare
## 2 10 9.3 38 NA NA None
## 3 33 29.7 38 NA NA None
## 4 7 6.6 33 NA NA None
## 5 8 6.6 36 NA NA None
## 6 5 5.1 38 NA NA None
## flodfreqmax pondfreqprs aws025wta aws050wta aws0100wta aws0150wta
## 1 Rare 0 3.52 7.05 14.72 22.92
## 2 None 0 3.17 5.03 5.22 5.22
## 3 None 0 3.15 4.99 5.14 5.14
## 4 None 0 2.84 3.94 4.04 4.04
## 5 None 0 3.14 5.20 6.27 6.51
## 6 None 0 3.56 5.47 5.62 5.62
## drclassdcd drclasswettest hydgrpdcd iccdcd iccdcdpct niccdcd niccdcdpct
## 1 Well drained Well drained B 1 89 3 100
## 2 Well drained Well drained D 7 85 7 85
## 3 Well drained Well drained D 7 85 7 85
## 4 Well drained Well drained D 7 85 7 85
## 5 Well drained Well drained D 7 55 7 55
## 6 Well drained Well drained D 6 92 6 92
## engdwobdcd engdwbdcd engdwbll engdwbml engstafdcd
## 1 Very limited Very limited Not limited Very limited Somewhat limited
## 2 Somewhat limited Very limited Somewhat limited Very limited Very limited
## 3 Very limited Very limited Not rated Very limited Very limited
## 4 Somewhat limited Very limited Very limited Very limited Very limited
## 5 Somewhat limited Very limited Somewhat limited Very limited Very limited
## 6 Very limited Very limited Very limited Very limited Very limited
## engstafll engstafml engsldcd engsldcp englrsdcd
## 1 Somewhat limited Very limited Very limited Very limited Somewhat limited
## 2 Very limited Very limited Very limited Very limited Somewhat limited
## 3 Not rated Very limited Very limited Very limited Very limited
## 4 Very limited Very limited Very limited Very limited Somewhat limited
## 5 Very limited Very limited Very limited Very limited Somewhat limited
## 6 Very limited Very limited Very limited Very limited Very limited
## engcmssdcd engcmssmp urbrecptdcd urbrecptwta forpehrtdcp
## 1 Poor Fair Somewhat limited 0.248 Erosion hazard slight
## 2 Fair Fair Somewhat limited 0.106 Erosion hazard moderate
## 3 Fair Not rated Very limited 0.924 Erosion hazard severe
## 4 Fair Fair Somewhat limited 0.122 Erosion hazard slight
## 5 Poor Poor Somewhat limited 0.350 Erosion hazard moderate
## 6 Poor Fair Somewhat limited 0.505 Erosion hazard moderate
## hydclprs awmmfpwwta
## 1 0 0.102
## 2 2 1.000
## 3 0 1.000
## 4 2 1.000
## 5 0 0.996
## 6 3 1.000
str(muagg)## 'data.frame': 129 obs. of 40 variables:
## $ mukey : int 2924907 2924879 2924880 2924881 2924882 2924883 2924913 2924908 2924884 2924885 ...
## $ musym : chr "128" "206" "207" "208" ...
## $ muname : chr "Cogna loam, 0 to 2 percent slopes, overwash" "Pentz sandy loam, 2 to 15 percent slopes" "Pentz sandy loam, 15 to 50 percent slopes" "Pentz cobbly sandy loam, 2 to 8 percent slopes" ...
## $ mustatus : chr NA NA NA NA ...
## $ slopegraddcp : num 1 10 33 7 8 5 1 1 3 8 ...
## $ slopegradwta : num 1 9.3 29.7 6.6 6.6 5.1 1.1 1.1 3.9 6.8 ...
## $ brockdepmin : int NA 38 38 33 36 38 NA NA 35 31 ...
## $ wtdepannmin : int NA NA NA NA NA NA 43 NA NA NA ...
## $ wtdepaprjunmin: int NA NA NA NA NA NA NA NA NA NA ...
## $ flodfreqdcd : chr "Rare" "None" "None" "None" ...
## $ flodfreqmax : chr "Rare" "None" "None" "None" ...
## $ pondfreqprs : chr "0" "0" "0" "0" ...
## $ aws025wta : num 3.52 3.17 3.15 2.84 3.14 3.56 3 3.96 3.39 3.26 ...
## $ aws050wta : num 7.05 5.03 4.99 3.94 5.2 5.47 5.51 7.98 5.21 4.49 ...
## $ aws0100wta : num 14.72 5.22 5.14 4.04 6.27 ...
## $ aws0150wta : num 22.92 5.22 5.14 4.04 6.51 ...
## $ drclassdcd : chr "Well drained" "Well drained" "Well drained" "Well drained" ...
## $ drclasswettest: chr "Well drained" "Well drained" "Well drained" "Well drained" ...
## $ hydgrpdcd : chr "B" "D" "D" "D" ...
## $ iccdcd : chr "1" "7" "7" "7" ...
## $ iccdcdpct : int 89 85 85 85 55 92 85 74 60 88 ...
## $ niccdcd : chr "3" "7" "7" "7" ...
## $ niccdcdpct : int 100 85 85 85 55 92 85 95 60 88 ...
## $ engdwobdcd : chr "Very limited" "Somewhat limited" "Very limited" "Somewhat limited" ...
## $ engdwbdcd : chr "Very limited" "Very limited" "Very limited" "Very limited" ...
## $ engdwbll : chr "Not limited" "Somewhat limited" "Not rated" "Very limited" ...
## $ engdwbml : chr "Very limited" "Very limited" "Very limited" "Very limited" ...
## $ engstafdcd : chr "Somewhat limited" "Very limited" "Very limited" "Very limited" ...
## $ engstafll : chr "Somewhat limited" "Very limited" "Not rated" "Very limited" ...
## $ engstafml : chr "Very limited" "Very limited" "Very limited" "Very limited" ...
## $ engsldcd : chr "Very limited" "Very limited" "Very limited" "Very limited" ...
## $ engsldcp : chr "Very limited" "Very limited" "Very limited" "Very limited" ...
## $ englrsdcd : chr "Somewhat limited" "Somewhat limited" "Very limited" "Somewhat limited" ...
## $ engcmssdcd : chr "Poor" "Fair" "Fair" "Fair" ...
## $ engcmssmp : chr "Fair" "Fair" "Not rated" "Fair" ...
## $ urbrecptdcd : chr "Somewhat limited" "Somewhat limited" "Very limited" "Somewhat limited" ...
## $ urbrecptwta : num 0.248 0.106 0.924 0.122 0.35 0.505 0.624 0.368 0.489 0.46 ...
## $ forpehrtdcp : chr "Erosion hazard slight" "Erosion hazard moderate" "Erosion hazard severe" "Erosion hazard slight" ...
## $ hydclprs : int 0 2 0 2 0 3 2 0 0 0 ...
## $ awmmfpwwta : num 0.102 1 1 1 0.996 1 1 0.89 0.995 1 ...
## - attr(*, "SDA_id")= chr "Table"This function returns a data frame with one row per map unit,
containing dozens of pre-calculated aggregate properties. See the
get_SDA_muaggatt() documentation for the full list of
available columns.
Filtering Results
You can filter by area symbol, map unit key, or custom WHERE clause:
# Get aggregate attributes for specific mukeys
muagg_filtered <- get_SDA_muaggatt(
mukeys = c(461994, 461995, 463264)
)
head(muagg_filtered)## mukey musym muname mustatus
## 1 461994 102 Alamo clay, 0 to 2 percent slopes <NA>
## 2 461995 103 Alo-Vaquero complex, 8 to 30 percent slopes, MLRA 15 <NA>
## 3 463264 DbE Daulton very rocky loam, 15 to 30 percent slopes <NA>
## slopegraddcp slopegradwta brockdepmin wtdepannmin wtdepaprjunmin flodfreqdcd
## 1 1 1.0 NA 15 15 Rare
## 2 23 23.0 64 NA NA None
## 3 23 24.3 0 NA NA None
## flodfreqmax pondfreqprs aws025wta aws050wta aws0100wta aws0150wta
## 1 Rare 0 3.75 7.30 12.06 12.06
## 2 None 0 3.74 7.52 11.43 11.43
## 3 None 0 4.25 6.12 6.12 6.12
## drclassdcd drclasswettest hydgrpdcd iccdcd iccdcdpct niccdcd niccdcdpct
## 1 Poorly drained Poorly drained D 3 85 4 85
## 2 Well drained Well drained D <NA> 100 4 85
## 3 Well drained Well drained D 6 65 6 65
## engdwobdcd engdwbdcd engdwbll engdwbml engstafdcd engstafll
## 1 Very limited Very limited Not rated Very limited Very limited Not rated
## 2 Very limited Very limited Not rated Very limited Very limited Not rated
## 3 Very limited Very limited Not rated Very limited Very limited Not rated
## engstafml engsldcd engsldcp englrsdcd engcmssdcd engcmssmp
## 1 Very limited Very limited Very limited Very limited Poor Not rated
## 2 Very limited Very limited Very limited Very limited Poor Not rated
## 3 Very limited Very limited Very limited Very limited Poor Not rated
## urbrecptdcd urbrecptwta forpehrtdcp hydclprs awmmfpwwta
## 1 Very limited 1.00 Erosion hazard slight 93 1
## 2 Somewhat limited 0.92 Erosion hazard moderate 0 1
## 3 Very limited 1.00 Erosion hazard very severe 0 1
get_SDA_pmgroupname(): Parent Material Groups
Parent material groups classify the primary geological or organic
origin of soil material. The get_SDA_pmgroupname() function
retrieves parent material classifications by component.
Method: DOMINANT COMPONENT
Get parent material from the dominant component:
pm_dom <- get_SDA_pmgroupname(
areasymbols = "CA630",
method = "DOMINANT COMPONENT",
simplify = FALSE
)
head(pm_dom)## mukey areasymbol musym
## 1 3225132 CA630 7065
## 2 3356289 CA630 6206
## 3 2600458 CA630 7212
## 4 2450845 CA630 3058
## 5 2924913 CA630 220
## 6 2403696 CA630 5100
## muname
## 1 Bonanza-Loafercreek complex, 3 to 15 percent slopes, low precipitation
## 2 Musick-Hotaw complex, 8 to 30 percent slopes
## 3 Wardsferry-Millvilla complex, 30 to 60 percent slopes
## 4 Shawsflat-Angelscreek complex, 25 to 60 percent slopes
## 5 Redding gravelly loam, 0 to 8 percent slopes, dry
## 6 Mokelumne-Buenavista-Aquultic Haploxeralfs, occasionally ponded complex, 1 to 12 percent slopes
## compname compkind comppct_r majcompflag
## 1 Bonanza Series 70 Yes
## 2 Musick Series 64 Yes
## 3 Wardsferry Series 50 Yes
## 4 Shawsflat Series 65 Yes
## 5 Redding Series 85 Yes
## 6 Mokelumne Series 40 Yes
## pmgroupname
## 1 colluvium over residuum derived from metavolcanics
## 2 colluvium over residuum derived from diorite
## 3 colluvium over residuum derived from metasedimentary rock
## 4 colluvium derived from latite over residuum weathered from volcanic rock
## 5 loamy alluvium derived from igneous, metamorphic and sedimentary rock over clayey alluvium derived from igneous, metamorphic and sedimentary rock over cemented alluvium derived from igneous, metamorphic and sedimentary rock
## 6 slope alluvium derived from sandstone over residuum weathered from sandstoneMethod: DOMINANT CONDITION
Aggregate parent materials by group, then return the dominant:
pm_cond <- get_SDA_pmgroupname(
mukeys = c(461994, 461995, 462205),
method = "DOMINANT CONDITION"
)
head(pm_cond)## mukey areasymbol musym
## 1 461994 CA077 102
## 2 461995 CA077 103
## 3 462205 CA624 AzE
## muname
## 1 Alamo clay, 0 to 2 percent slopes
## 2 Alo-Vaquero complex, 8 to 30 percent slopes, MLRA 15
## 3 Auburn cobbly clay loam, heavy subsoil variant, 9 to 50 percent slopes
## pmgroupname
## 1 Waterlaid (or Transported) Deposits
## 2 In-Place Deposits (nontransported)
## 3 In-Place Deposits (nontransported)Simplify Parameter
By default, simplify = TRUE groups parent materials into
broader categories. Set simplify = FALSE to get detailed
group names:
# Simplified (broader groups)
pm_simple <- get_SDA_pmgroupname(
mukeys = c(461994, 461995),
simplify = TRUE
)
head(pm_simple)## mukey areasymbol musym muname
## 1 461994 CA077 102 Alamo clay, 0 to 2 percent slopes
## 2 461995 CA077 103 Alo-Vaquero complex, 8 to 30 percent slopes, MLRA 15
## compname compkind comppct_r majcompflag pmgroupname
## 1 Alamo Series 85 Yes Waterlaid (or Transported) Deposits
## 2 Alo Series 45 Yes In-Place Deposits (nontransported)
# Detailed (specific groups)
pm_detailed <- get_SDA_pmgroupname(
mukeys = c(461994, 461995),
simplify = FALSE
)
head(pm_detailed)## mukey areasymbol musym muname
## 1 461995 CA077 103 Alo-Vaquero complex, 8 to 30 percent slopes, MLRA 15
## 2 461994 CA077 102 Alamo clay, 0 to 2 percent slopes
## compname compkind comppct_r majcompflag
## 1 Alo Series 45 Yes
## 2 Alamo Series 85 Yes
## pmgroupname
## 1 residuum weathered from sandstone and shale
## 2 alluvium from mixed rock sources
get_SDA_coecoclass(): Component Ecological Classes
Ecological classes describe potential natural vegetation and
ecological conditions. The get_SDA_coecoclass() function
retrieves ecological site classifications by component.
A worked example of this function is available in the “Dominant Ecological Site” vignette.
Method: NONE (Default)
Return component-level ecological classes without aggregation:
eco_none <- get_SDA_coecoclass(
method = "None",
areasymbols = "CA630"
)
head(eco_none)## mukey areasymbol lkey muname cokey
## 1 2924907 CA630 14103 Cogna loam, 0 to 2 percent slopes, overwash 26412197
## 2 2924907 CA630 14103 Cogna loam, 0 to 2 percent slopes, overwash 26412198
## 3 2924907 CA630 14103 Cogna loam, 0 to 2 percent slopes, overwash 26412199
## 4 2924907 CA630 14103 Cogna loam, 0 to 2 percent slopes, overwash 26412200
## 5 2924907 CA630 14103 Cogna loam, 0 to 2 percent slopes, overwash 26412201
## 6 2924907 CA630 14103 Cogna loam, 0 to 2 percent slopes, overwash 26412202
## coecoclasskey comppct_r majcompflag compname localphase
## 1 NA 1 No Columbia occasionally flooded
## 2 NA 3 No Veritas fine sandy loam
## 3 NA 6 No Archerdale clay loam
## 4 NA 4 No Nord loam
## 5 NA 1 No Honcut sandy loam
## 6 12406649 85 Yes Cogna <NA>
## compkind ecoclassid ecoclassname ecoclasstypename
## 1 Series Not assigned Not assigned Not assigned
## 2 Series Not assigned Not assigned Not assigned
## 3 Series Not assigned Not assigned Not assigned
## 4 Taxadjunct Not assigned Not assigned Not assigned
## 5 Series Not assigned Not assigned Not assigned
## 6 Series R017XY905CA Dry Alluvial Fans and Terraces NRCS Rangeland Site
## ecoclassref
## 1 Not assigned
## 2 Not assigned
## 3 Not assigned
## 4 Not assigned
## 5 Not assigned
## 6 Ecological Site Description DatabaseThe default behavior targets the NRCS Ecological Site database-related entries, but there are many other ecological/vegetation class types in SSURGO.
Columns include:
ecoclassid- Ecological Class IDecoclassname- Full ecological class nameecoclasstypename- Type (e.g.,"NRCS Rangeland Site","NRCS Forestland Site")ecoclassref- Reference document
Method: DOMINANT COMPONENT
Get ecological site from the dominant component only:
eco_dom <- get_SDA_coecoclass(
method = "Dominant Component",
areasymbols = "CA630"
)
head(eco_dom)## mukey areasymbol lkey muname
## 6 2924907 CA630 14103 Cogna loam, 0 to 2 percent slopes, overwash
## 7 2924879 CA630 14103 Pentz sandy loam, 2 to 15 percent slopes
## 15 2924880 CA630 14103 Pentz sandy loam, 15 to 50 percent slopes
## 27 2924881 CA630 14103 Pentz cobbly sandy loam, 2 to 8 percent slopes
## 31 2924882 CA630 14103 Pentz-Bellota complex, 2 to 15 percent slopes
## 34 2924883 CA630 14103 Peters clay, 2 to 8 percent slopes
## cokey coecoclasskey comppct_r majcompflag compname localphase compkind
## 6 26412202 12406649 85 Yes Cogna <NA> Series
## 7 26412137 12406603 85 Yes Pentz <NA> Series
## 15 26412145 12406611 85 Yes Pentz <NA> Series
## 27 26412157 12406621 85 Yes Pentz <NA> Series
## 31 26412161 12406625 55 Yes Pentz silt loam Series
## 34 26412164 12406626 85 Yes Peters <NA> Series
## ecoclassid ecoclassname ecoclasstypename
## 6 R017XY905CA Dry Alluvial Fans and Terraces NRCS Rangeland Site
## 7 R018XI163CA Thermic Low Rolling Hills NRCS Rangeland Site
## 15 R018XI163CA Thermic Low Rolling Hills NRCS Rangeland Site
## 27 R018XI163CA Thermic Low Rolling Hills NRCS Rangeland Site
## 31 R018XI163CA Thermic Low Rolling Hills NRCS Rangeland Site
## 34 R018XI164CA Clayey Dissected Swales NRCS Rangeland Site
## ecoclassref
## 6 Ecological Site Description Database
## 7 Ecological Site Description Database
## 15 Ecological Site Description Database
## 27 Ecological Site Description Database
## 31 Ecological Site Description Database
## 34 Ecological Site Description DatabaseMethod: DOMINANT CONDITION
Aggregate ecological classes by ID, then return the dominant:
eco_cond <- get_SDA_coecoclass(
method = "Dominant Condition",
mukeys = c(461994, 461995, 462205),
ecoclasstypename = "NRCS Forestland Site"
)
head(eco_cond)## mukey areasymbol lkey
## 5 461994 CA077 14086
## 11 461995 CA077 14086
## 12 462205 CA624 14101
## muname
## 5 Alamo clay, 0 to 2 percent slopes
## 11 Alo-Vaquero complex, 8 to 30 percent slopes, MLRA 15
## 12 Auburn cobbly clay loam, heavy subsoil variant, 9 to 50 percent slopes
## cokey coecoclasskey comppct_r majcompflag compname localphase compkind
## 5 27537144 NA 85 Yes Alamo <NA> Series
## 11 27537150 NA 45 Yes Alo <NA> Series
## 12 26397614 12405152 85 Yes Auburn variant Variant
## ecoclassid ecoclassname ecoclasstypename
## 5 Not assigned Not assigned NRCS Forestland Site
## 11 Not assigned Not assigned NRCS Forestland Site
## 12 F018XI201CA Moderately Deep Thermic Foothills NRCS Forestland Site
## ecoclassref ecoclasspct_r
## 5 Not assigned 100
## 11 Not assigned 100
## 12 Ecological Site Description Database 85Method: ALL
Return all ecological sites per map unit in wide format:
eco_all <- get_SDA_coecoclass(
method = "All",
mukeys = c(461994, 461995),
threshold = 5
)
head(eco_all)## mukey muname nationalmusym
## <int> <char> <char>
## 1: 461994 Alamo clay, 0 to 2 percent slopes hhr1
## 2: 461995 Alo-Vaquero complex, 8 to 30 percent slopes, MLRA 15 2tyzk
## site1 site1name site1compname site1pct_r
## <char> <char> <char> <int>
## 1: R017XY902CA Duripan Vernal Pools Alamo 85
## 2: R015XE001CA Clayey Hills 10-14" p.z. Alo, Vaquero 85
## site1link site2
## <char> <char>
## 1: https://edit.jornada.nmsu.edu/catalogs/esd/017X/R017XY902CA Not assigned
## 2: https://edit.jornada.nmsu.edu/catalogs/esd/015X/R015XE001CA Not assigned
## site2name site2compname site2pct_r site2link
## <char> <char> <int> <char>
## 1: Not assigned Alamo, Madera, San Joaquin, Redding 15 <NA>
## 2: Not assigned Arburua, Wisflat, San Timoteo, Calla 15 <NA>Filtering by ecological class type:
# Get rangeland sites only
eco_range <- get_SDA_coecoclass(
method = "Dominant Condition",
areasymbols = "CA630",
ecoclasstypename = "NRCS Rangeland Site"
)
head(eco_range)## mukey areasymbol lkey muname
## 6 2924907 CA630 14103 Cogna loam, 0 to 2 percent slopes, overwash
## 7 2924879 CA630 14103 Pentz sandy loam, 2 to 15 percent slopes
## 15 2924880 CA630 14103 Pentz sandy loam, 15 to 50 percent slopes
## 27 2924881 CA630 14103 Pentz cobbly sandy loam, 2 to 8 percent slopes
## 31 2924882 CA630 14103 Pentz-Bellota complex, 2 to 15 percent slopes
## 34 2924883 CA630 14103 Peters clay, 2 to 8 percent slopes
## cokey coecoclasskey comppct_r majcompflag compname localphase compkind
## 6 26412202 12406649 85 Yes Cogna <NA> Series
## 7 26412137 12406603 85 Yes Pentz <NA> Series
## 15 26412145 12406611 85 Yes Pentz <NA> Series
## 27 26412157 12406621 85 Yes Pentz <NA> Series
## 31 26412161 12406625 55 Yes Pentz silt loam Series
## 34 26412164 12406626 85 Yes Peters <NA> Series
## ecoclassid ecoclassname ecoclasstypename
## 6 R017XY905CA Dry Alluvial Fans and Terraces NRCS Rangeland Site
## 7 R018XI163CA Thermic Low Rolling Hills NRCS Rangeland Site
## 15 R018XI163CA Thermic Low Rolling Hills NRCS Rangeland Site
## 27 R018XI163CA Thermic Low Rolling Hills NRCS Rangeland Site
## 31 R018XI163CA Thermic Low Rolling Hills NRCS Rangeland Site
## 34 R018XI164CA Clayey Dissected Swales NRCS Rangeland Site
## ecoclassref ecoclasspct_r
## 6 Ecological Site Description Database 85
## 7 Ecological Site Description Database 94
## 15 Ecological Site Description Database 96
## 27 Ecological Site Description Database 92
## 31 Ecological Site Description Database 88
## 34 Ecological Site Description Database 85
get_SDA_cosurfmorph(): Component Surface
Morphometry
Surface morphometry describes the three-dimensional shape and
position of a landscape. The get_SDA_cosurfmorph() function
returns component-level geomorphic classifications aggregated in various
ways.
Available Tables
SDA contains four cosurfmorph tables:
| Table | Variables | Description |
|---|---|---|
cosurfmorphgc |
geomposmntn, geomposhill,
geomposflats, geompostrce
|
3D geomorphic classification |
cosurfmorphhpp |
hillslopeprof |
2D hillslope position profile |
cosurfmorphss |
shapeacross, shapedown
|
Surface shape (convex/concave/linear) |
cosurfmorphmr |
geomicrorelief |
Microrelief (slope complexity) |
Example: 3D Geomorphic Classification
# Get geomorphic position by component name
geom_3d <- get_SDA_cosurfmorph(
table = "cosurfmorphgc",
areasymbols = "CA630"
)
head(geom_3d)## mukey geomposmntn geomposmntn_n p_geomposmntn geomposhill geomposhill_n
## 1 1865918 <NA> 0 0 Interfluve 4
## 2 1865926 <NA> 0 0 Side Slope 5
## 3 1865927 <NA> 0 0 Side Slope 3
## 4 1865928 <NA> 0 0 Side Slope 2
## 5 1865929 <NA> 0 0 Interfluve 1
## 6 1865929 <NA> 0 0 Nose Slope 1
## p_geomposhill geomposflats geomposflats_n p_geomposflats geompostrce
## 1 1.0 <NA> 0 0 <NA>
## 2 1.0 <NA> 0 0 <NA>
## 3 1.0 <NA> 0 0 <NA>
## 4 1.0 <NA> 0 0 <NA>
## 5 0.5 <NA> 0 0 <NA>
## 6 0.5 <NA> 0 0 <NA>
## geompostrce_n p_geompostrce total
## 1 0 0 4
## 2 0 0 5
## 3 0 0 3
## 4 0 0 2
## 5 0 0 2
## 6 0 0 2Output includes columns like:
compname- Component namegeomposmntn,geomposmntn_n- Mountain position (count)p_geomposmntn- Mountain position proportion
Example: Hillslope Position by Area
# Get hillslope position aggregated by area symbol
geom_hill <- get_SDA_cosurfmorph(
table = "cosurfmorphhpp",
by = "areasymbol",
areasymbols = "CA630"
)
head(geom_hill)## areasymbol hillslopeprof hillslopeprof_n p_hillslopeprof total
## 1 CA630 Backslope 260 0.48 546
## 2 CA630 Shoulder 114 0.21 546
## 3 CA630 Footslope 78 0.14 546
## 4 CA630 Summit 76 0.14 546
## 5 CA630 Toeslope 18 0.03 546Example: Surface Shape
# Get surface shape classes
geom_shape <- get_SDA_cosurfmorph(
table = "cosurfmorphss",
areasymbols = "CA649"
)
head(geom_shape)## mukey shapeacross shapeacross_n p_shapeacross shapedown shapedown_n
## 1 463229 Convex 1 1 Concave 1
## 2 463230 Convex 1 1 Concave 1
## 3 463231 Convex 3 1 Concave 3
## 4 463232 Convex 3 1 Concave 3
## 5 463233 Convex 3 1 Concave 3
## 6 463234 Convex 2 1 Concave 2
## p_shapedown surfaceshape surfaceshape_n p_surfaceshape total
## 1 1 Convex/Concave 1 1 1
## 2 1 Convex/Concave 1 1 1
## 3 1 Convex/Concave 3 1 3
## 4 1 Convex/Concave 3 1 3
## 5 1 Convex/Concave 3 1 3
## 6 1 Convex/Concave 2 1 2Example: Microrelief
# Get microrelief by component name
geom_micro <- get_SDA_cosurfmorph(
table = "cosurfmorphmr",
areasymbols = "CA630"
)
head(geom_micro)## mukey geomicrorelief geomicrorelief_n p_geomicrorelief total
## 1 1865918 Microhigh 3 0.75 4
## 2 1865918 Microlow 1 0.25 4
## 3 2403696 Microlow 1 1.00 1
## 4 2600537 Microhigh 1 1.00 1
## 5 2766838 Microhigh 1 0.50 2
## 6 2766838 Microlow 1 0.50 2
fetchSDA(): Get Soil Profile Collection
The fetchSDA() function is a high-level wrapper around
SDA_query() that simplifies the process of downloading and
assembling soil profile data into a SoilProfileCollection
object from the package aqp. It automatically handles the
complex joins between map unit, component, and horizon tables.
Basic Usage
You can fetch all components and horizons for a specific area or set
of map units using the WHERE argument:
library(aqp)
# Query soil components by areasymbol and musym
s <- fetchSDA(WHERE = "areasymbol = 'IN005' AND musym = 'MnpB2'")
# The result is a SoilProfileCollection
print(s)## SoilProfileCollection with 4 profiles and 20 horizons
## profile ID: cokey | horizon ID: chkey
## Depth range: 200 - 200 cm
##
## ----- Horizons (6 / 20 rows | 10 / 64 columns) -----
## cokey chkey hzdept_r hzdepb_r hzname texture texcl lieutex
## 26474693 78997358 0 25 Ap sil Silt loam <NA>
## 26474693 78997359 25 35 A sil Silt loam <NA>
## 26474693 78997360 35 91 Btg1 sicl Silty clay loam <NA>
## 26474693 78997361 91 150 2Btg2 l Loam <NA>
## 26474693 78997362 150 200 2C l Loam <NA>
## 26474694 78997365 0 41 Ap sicl Silty clay loam <NA>
## fragvol_l fragvol_r
## 0 0
## 0 0
## 0 0
## 1 5
## 1 6
## NA NA
## [... more horizons ...]
##
## ----- Sites (4 / 4 rows | 10 / 101 columns) -----
## mukey nationalmusym cokey compname comppct_r compkind majcompflag
## NA 2zss9 26474693 Treaty 2 Series No
## NA 2zss9 26474694 Brookston 4 Series No
## NA 2zss9 26474695 Miami 85 Series Yes
## NA 2zss9 26474696 Crosby 9 Series No
## localphase drainagecl hydricrating
## frequently ponded, drained Poorly drained Yes
## <NA> Poorly drained Yes
## eroded Moderately well drained No
## eroded Somewhat poorly drained No
##
## Spatial Data:
## [EMPTY]## chkey hzname hzdept_r hzdepb_r texture texcl lieutex fragvol_l
## 1 78997358 Ap 0 25 sil Silt loam <NA> 0
## 2 78997359 A 25 35 sil Silt loam <NA> 0
## 3 78997360 Btg1 35 91 sicl Silty clay loam <NA> 0
## 4 78997361 2Btg2 91 150 l Loam <NA> 1
## 5 78997362 2C 150 200 l Loam <NA> 1
## 6 78997365 Ap 0 41 sicl Silty clay loam <NA> NA
## fragvol_r fragvol_h sandtotal_l sandtotal_r sandtotal_h silttotal_l
## 1 0 2 5 17 20 40
## 2 0 2 5 16 20 40
## 3 0 2 5 12 15 50
## 4 5 9 15 30 45 22
## 5 6 13 30 40 60 22
## 6 NA NA 5 13 19 50
## silttotal_r silttotal_h claytotal_l claytotal_r claytotal_h om_l om_r om_h
## 1 59 80 9 24 40 3.0 4.50 6
## 2 58 80 9 26 40 2.0 4.00 6
## 3 55 66 24 33 35 1.0 1.50 2
## 4 44 65 20 26 35 0.5 0.75 1
## 5 42 50 10 18 20 0.0 0.50 1
## 6 59 67 28 28 35 3.0 4.00 6
## dbthirdbar_l dbthirdbar_r dbthirdbar_h ksat_l ksat_r ksat_h awc_l awc_r awc_h
## 1 1.34 1.38 1.43 4.23 9.17 14.11 0.17 0.21 0.24
## 2 1.26 1.31 1.35 4.23 9.17 14.11 0.17 0.21 0.24
## 3 1.33 1.35 1.37 4.23 9.17 14.11 0.14 0.16 0.21
## 4 1.38 1.48 1.58 4.23 9.17 14.11 0.07 0.14 0.21
## 5 1.37 1.46 1.56 1.41 2.82 4.23 0.01 0.08 0.15
## 6 1.30 1.45 1.60 4.23 9.17 14.11 0.15 0.17 0.25
## lep_r sar_r ec_r cec7_r sumbases_r ph1to1h2o_l ph1to1h2o_r ph1to1h2o_h
## 1 3.4 0 0 20.7 19.1 5.6 6.5 7.3
## 2 3.8 0 0 22.2 20.3 5.6 6.5 7.3
## 3 5.3 0 0 26.5 26.0 6.1 7.0 7.8
## 4 3.3 0 0 20.3 59.0 6.6 7.5 8.4
## 5 1.5 0 0 13.0 51.7 7.4 7.9 8.4
## 6 4.3 0 0 23.7 21.3 5.6 6.5 7.3
## caco3_l caco3_r caco3_h kwfact kffact cokey nasischiid fine_gravel gravel
## 1 0 0 0 .32 .32 26474693 11469785 0 0
## 2 0 0 0 .24 .24 26474693 11469786 0 0
## 3 0 0 0 .32 .32 26474693 11469787 0 0
## 4 0 13 25 .37 .37 26474693 11469788 3 5
## 5 15 28 40 .43 .43 26474693 11469784 0 2
## 6 0 0 0 .28 .28 26474694 11469791 0 0
## cobbles stones boulders channers flagstones parafine_gravel paragravel
## 1 0 0 0 0 0 0 0
## 2 0 0 0 0 0 0 0
## 3 0 0 0 0 0 0 0
## 4 0 0 0 0 0 0 0
## 5 1 0 0 3 0 0 0
## 6 0 0 0 0 0 0 0
## paracobbles parastones paraboulders parachanners paraflagstones unspecified
## 1 0 0 0 0 0 0
## 2 0 0 0 0 0 0
## 3 0 0 0 0 0 0
## 4 0 0 0 0 0 0
## 5 0 0 0 0 0 0
## 6 0 0 0 0 0 0
## total_frags_pct_nopf total_frags_pct hzID
## 1 0 0 1
## 2 0 0 2
## 3 0 0 3
## 4 5 5 4
## 5 6 6 5
## 6 0 0 6This function is very powerful for getting a quick snapshot of the soil profiles in an area.
It is worth noting that fetchSDA() returns data from
both SSURGO and STATSGO2. To limit to SSURGO, use
WHERE = "areasymbol != 'US'" (see the Data Filtering
section), or specify a SSURGO area symbol.
Handling Duplicates
The duplicates argument (defaulting to
FALSE) controls how components that appear in multiple
survey areas are handled.
-
duplicates = FALSE(Default): Returns only one instance of a component pernationalmusym. This eliminates “duplication” where multiple survey area (legend) map units are linked to the same sourcemapunitandcomponentrecords. This is generally preferred for statistical analysis of soil properties. -
duplicates = TRUE: Returns a record for each unique map unit key (mukey). This is useful for visualization or when you need to account for every occurrence of a component across different survey area correlations.
fetchLDM(): Get Laboratory Data
The fetchLDM() function provides access to the Kellogg
Soil Survey Laboratory (KSSL) Data Mart via Soil Data Access. It allows
for querying laboratory data by various criteria and returning it as a
SoilProfileCollection.
Basic Usage
You can fetch lab data by specifying an identifier (like an area
symbol) and the column it corresponds to (what
argument):
# Fetch KSSL data for a specific soil survey area (CA630)
# 'what' argument specifies we are searching by 'area_code'
# 'tables' argument specifies which data tables to include (defaults to core tables)
ldm_data <- fetchLDM("CA630", what = "area_code")
# The result is a SoilProfileCollection
print(ldm_data)## SoilProfileCollection with 175 profiles and 800 horizons
## profile ID: pedon_key | horizon ID: hzID
## Depth range: 13 - 321 cm
##
## ----- Horizons (6 / 800 rows | 10 / 432 columns) -----
## pedon_key hzID hzn_top hzn_bot hzn_desgn layer_key labsampnum project_key
## 34047 1 0 3 Oi 206399 07N03070 4919
## 34047 2 3 5 Oe 206400 07N03071 4919
## 34047 3 5 15 A1 206401 07N03072 4919
## 34047 4 15 28 A2 206402 07N03073 4919
## 34047 5 28 46 BE 206403 07N03074 4919
## 34047 6 46 71 2Bt1 206404 07N03075 4919
## layer_sequence layer_type
## 1 horizon
## 2 horizon
## 3 horizon
## 4 horizon
## 5 horizon
## 6 horizon
## [... more horizons ...]
##
## ----- Sites (6 / 175 rows | 10 / 126 columns) -----
## pedon_key site_key pedlabsampnum pedoniid upedonid labdatadescflag
## 34047 33850 07N0468 242796 S2007CA009001 1
## 34048 33851 07N0469 242808 S2007CA009002 1
## 34049 33852 07N0470 242805 S2007CA109001 1
## 34050 33853 07N0471 242797 S2007CA109002 1
## 34051 33854 07N0472 242798 S2007CA109003 1
## 34052 33855 07N0473 207254 S2007CA109004 1
## priority priority2 samp_name samp_class_type
## B A Sitesnot series
## B A Gopheridge series
## B A Motherlode series
## B A Hennekenot series
## B A Whiterock series
## B A Musick (fine) series
## [... more sites ...]
##
## Spatial Data:
## [EMPTY]## pedon_key site_key pedlabsampnum pedoniid upedonid labdatadescflag
## 1 34047 33850 07N0468 242796 S2007CA009001 1
## 2 34048 33851 07N0469 242808 S2007CA009002 1
## 3 34049 33852 07N0470 242805 S2007CA109001 1
## 4 34050 33853 07N0471 242797 S2007CA109002 1
## 5 34051 33854 07N0472 242798 S2007CA109003 1
## 6 34052 33855 07N0473 207254 S2007CA109004 1
## priority priority2 samp_name samp_class_type samp_classdate
## 1 B A Sitesnot series 4/5/2007 12:00:00 AM
## 2 B A Gopheridge series 4/2/2007 12:00:00 AM
## 3 B A Motherlode series 4/5/2007 12:00:00 AM
## 4 B A Hennekenot series 4/11/2007 12:00:00 AM
## 5 B A Whiterock series 3/29/2007 12:00:00 AM
## 6 B A Musick (fine) series 11/2/2006 12:00:00 AM
## samp_classification_name samp_taxorder
## 1 Fine, parasesquic, mesic Xeric Haplohumult ultisols
## 2 Loamy-skeletal, mixed, superactive, thermic Mollic Haploxeralf alfisols
## 3 Fine, mixed, superactive, thermic Mollic Haploxeralf alfisols
## 4 Loamy-skeletal, magnesic, thermic Lithic Argixeroll mollisols
## 5 Loamy, mixed, superactive, thermic Lithic Haploxerept inceptisols
## 6 Fine-loamy, mixed, superactive, mesic Ultic Haploxeralf alfisols
## samp_taxsuborder samp_taxgrtgroup samp_taxsubgrp samp_taxpartsize
## 1 humults haplohumults xeric haplohumults fine
## 2 xeralfs haploxeralfs mollic haploxeralfs loamy-skeletal
## 3 xeralfs haploxeralfs mollic haploxeralfs fine
## 4 xerolls argixerolls lithic argixerolls loamy-skeletal
## 5 xerepts haploxerepts lithic haploxerepts loamy
## 6 xeralfs haploxeralfs ultic haploxeralfs fine-loamy
## samp_taxpartsizemod samp_taxceactcl samp_taxreaction samp_taxtempcl
## 1 <NA> <NA> <NA> mesic
## 2 <NA> superactive <NA> thermic
## 3 <NA> superactive <NA> thermic
## 4 <NA> <NA> <NA> thermic
## 5 <NA> superactive <NA> thermic
## 6 <NA> superactive <NA> mesic
## samp_taxmoistscl samp_taxtempregime samp_taxminalogy samp_taxother
## 1 <NA> <NA> <NA> <NA>
## 2 <NA> <NA> <NA> <NA>
## 3 <NA> <NA> <NA> <NA>
## 4 <NA> <NA> <NA> <NA>
## 5 <NA> <NA> <NA> <NA>
## 6 <NA> <NA> <NA> <NA>
## samp_osdtypelocflag corr_name corr_class_type corr_classdate
## 1 0 Sites series 1/3/2018 12:00:00 AM
## 2 0 Gopheridge series 1/24/2012 12:00:00 AM
## 3 0 <NA> <NA> <NA>
## 4 0 Sixbit series 7/19/2018 12:00:00 AM
## 5 0 Whiterock taxadjunct 1/24/2012 12:00:00 AM
## 6 0 Wukusick series 6/9/2017 12:00:00 AM
## corr_classification_name corr_taxorder
## 1 Fine, parasesquic, mesic Xeric Haplohumults ultisols
## 2 Loamy-skeletal, mixed, active, thermic Ultic Haploxeralfs alfisols
## 3 Coarse-loamy, mixed, superactive, thermic Typic Haploxerepts alfisols
## 4 Loamy-skeletal, magnesic, thermic Lithic Argixerolls mollisols
## 5 Loamy, mixed, superactive, thermic Lithic Haploxerepts inceptisols
## 6 Fine, mixed, subactive, mesic Ultic Palexeralfs alfisols
## corr_taxsuborder corr_taxgrtgroup corr_taxsubgrp corr_taxpartsize
## 1 humults haplohumults xeric haplohumults fine
## 2 xeralfs haploxeralfs ultic haploxeralfs loamy-skeletal
## 3 xeralfs haploxerepts typic haploxerepts coarse-loamy
## 4 xerolls argixerolls lithic argixerolls loamy-skeletal
## 5 xerepts haploxerepts lithic haploxerepts loamy
## 6 xeralfs palexeralfs ultic palexeralfs fine
## corr_taxpartsizemod corr_taxceactcl corr_taxreaction corr_taxtempcl
## 1 <NA> semiactive <NA> mesic
## 2 <NA> active <NA> thermic
## 3 <NA> superactive <NA> thermic
## 4 <NA> superactive <NA> thermic
## 5 <NA> superactive <NA> thermic
## 6 <NA> subactive <NA> mesic
## corr_taxmoistscl corr_taxtempregime corr_taxminalogy corr_taxother
## 1 typic mesic parasesquic <NA>
## 2 typic thermic mixed <NA>
## 3 typic thermic mixed <NA>
## 4 typic thermic magnesic <NA>
## 5 typic thermic mixed <NA>
## 6 typic mesic mixed <NA>
## corr_osdtypelocflag SSL_name SSL_class_type SSL_classdate
## 1 0 <NA> <NA> <NA>
## 2 1 <NA> <NA> <NA>
## 3 0 <NA> <NA> <NA>
## 4 1 <NA> <NA> <NA>
## 5 0 <NA> <NA> <NA>
## 6 1 <NA> <NA> <NA>
## SSL_classification_name SSL_taxorder SSL_taxsuborder SSL_taxgrtgroup
## 1 <NA> <NA> <NA> <NA>
## 2 <NA> <NA> <NA> <NA>
## 3 <NA> <NA> <NA> <NA>
## 4 <NA> <NA> <NA> <NA>
## 5 <NA> <NA> <NA> <NA>
## 6 <NA> <NA> <NA> <NA>
## SSL_taxsubgrp SSL_taxpartsize SSL_taxpartsizemod SSL_taxceactcl
## 1 <NA> <NA> <NA> <NA>
## 2 <NA> <NA> <NA> <NA>
## 3 <NA> <NA> <NA> <NA>
## 4 <NA> <NA> <NA> <NA>
## 5 <NA> <NA> <NA> <NA>
## 6 <NA> <NA> <NA> <NA>
## SSL_taxreaction SSL_taxtempcl SSL_taxmoistscl SSL_taxtempregime
## 1 <NA> <NA> <NA> <NA>
## 2 <NA> <NA> <NA> <NA>
## 3 <NA> <NA> <NA> <NA>
## 4 <NA> <NA> <NA> <NA>
## 5 <NA> <NA> <NA> <NA>
## 6 <NA> <NA> <NA> <NA>
## SSL_taxminalogy SSL_taxother SSL_osdtypelocflag siteiid usiteid
## 1 <NA> <NA> 0 254492 07-SMM-015
## 2 <NA> <NA> 0 254491 07-JCR-002
## 3 <NA> <NA> 0 254488 07-JCR-001
## 4 <NA> <NA> 0 254487 07-SMM-009
## 5 <NA> <NA> 0 254485 07-SMM-008
## 6 <NA> <NA> 0 254484 06-JCR-006
## site_obsdate latitude_decimal_degrees longitude_decimal_degrees
## 1 4/5/2007 12:00:00 AM 38.37947 -120.4417
## 2 4/2/2007 12:00:00 AM 37.94286 -120.7150
## 3 4/5/2007 12:00:00 AM 37.84808 -120.5607
## 4 4/11/2007 12:00:00 AM 37.86214 -120.5085
## 5 3/29/2007 12:00:00 AM 37.83278 -120.5163
## 6 11/2/2006 12:00:00 AM 37.98614 -120.2356
## country_key state_key county_key mlra_key ssa_key npark_key nforest_key
## 1 244 3951 4453 11322 8103 NA NA
## 2 244 3951 4453 7578 8103 NA NA
## 3 244 3951 4503 7578 8103 NA NA
## 4 244 3951 4503 7578 8103 NA NA
## 5 244 3951 4503 7578 8103 NA NA
## 6 244 3951 4503 7578 8103 NA NA
## note samp_taxfamhahatmatcl corr_taxfamhahatmatcl
## 1 NASIS updated 5/4/2020 7:44:44 AM <NA> <NA>
## 2 NASIS updated 5/4/2020 7:44:44 AM <NA> <NA>
## 3 NASIS updated 5/4/2020 7:44:44 AM <NA> <NA>
## 4 NASIS updated 5/4/2020 7:44:44 AM <NA> <NA>
## 5 NASIS updated 5/4/2020 7:44:44 AM <NA> <NA>
## 6 NASIS updated 5/4/2020 7:44:44 AM <NA> <NA>
## SSL_taxfamhahatmatcl pedobjupdate siteobjupdate wmiid
## 1 <NA> 12/11/2018 11:05:00 PM 9/14/2018 6:17:53 PM 24530
## 2 <NA> 12/27/2018 10:08:46 PM 9/14/2018 6:17:53 PM 24531
## 3 <NA> 6/9/2017 7:41:53 PM 9/14/2018 6:17:53 PM 24532
## 4 <NA> 7/19/2018 6:51:07 PM 8/10/2011 6:55:58 PM 24533
## 5 <NA> 12/30/2015 4:03:15 PM 9/14/2018 6:17:53 PM 24534
## 6 <NA> 12/7/2017 12:12:50 AM 9/14/2018 6:00:14 PM 24535
## Series User_pedon_ID pedon_Key peiid
## 1 Sites S2007CA009001 34047 242796
## 2 Gopheridge S2007CA009002 34048 242808
## 3 Motherlode S2007CA109001 34049 242805
## 4 Sixbit S2007CA109002 34050 242797
## 5 Whiterock S2007CA109003 34051 242798
## 6 Wukusick S2007CA109004 34052 207254
## Soil_Classification
## 1 Fine, parasesquic, mesic Xeric Haplohumults
## 2 Loamy-skeletal, mixed, active, thermic Ultic Haploxeralfs
## 3 Coarse-loamy, mixed, superactive, thermic Typic Haploxerepts
## 4 Loamy-skeletal, magnesic, thermic Lithic Argixerolls
## 5 Loamy, mixed, superactive, thermic Lithic Haploxerepts
## 6 Fine, mixed, subactive, mesic Ultic Palexeralfs
## Primary_Lab_Report
## 1 https://ncsslabdatamart.sc.egov.usda.gov/rptExecute.aspx?p=34047&r=1&submit1=Get+Report
## 2 https://ncsslabdatamart.sc.egov.usda.gov/rptExecute.aspx?p=34048&r=1&submit1=Get+Report
## 3 https://ncsslabdatamart.sc.egov.usda.gov/rptExecute.aspx?p=34049&r=1&submit1=Get+Report
## 4 https://ncsslabdatamart.sc.egov.usda.gov/rptExecute.aspx?p=34050&r=1&submit1=Get+Report
## 5 https://ncsslabdatamart.sc.egov.usda.gov/rptExecute.aspx?p=34051&r=1&submit1=Get+Report
## 6 https://ncsslabdatamart.sc.egov.usda.gov/rptExecute.aspx?p=34052&r=1&submit1=Get+Report
## Taxonomy_Report
## 1 https://ncsslabdatamart.sc.egov.usda.gov/rptExecute.aspx?p=34047&r=3&submit1=Get+Report
## 2 https://ncsslabdatamart.sc.egov.usda.gov/rptExecute.aspx?p=34048&r=3&submit1=Get+Report
## 3 https://ncsslabdatamart.sc.egov.usda.gov/rptExecute.aspx?p=34049&r=3&submit1=Get+Report
## 4 https://ncsslabdatamart.sc.egov.usda.gov/rptExecute.aspx?p=34050&r=3&submit1=Get+Report
## 5 https://ncsslabdatamart.sc.egov.usda.gov/rptExecute.aspx?p=34051&r=3&submit1=Get+Report
## 6 https://ncsslabdatamart.sc.egov.usda.gov/rptExecute.aspx?p=34052&r=3&submit1=Get+Report
## Supplementary_Lab_Report
## 1 https://ncsslabdatamart.sc.egov.usda.gov/rptExecute.aspx?p=34047&r=2&submit1=Get+Report
## 2 https://ncsslabdatamart.sc.egov.usda.gov/rptExecute.aspx?p=34048&r=2&submit1=Get+Report
## 3 https://ncsslabdatamart.sc.egov.usda.gov/rptExecute.aspx?p=34049&r=2&submit1=Get+Report
## 4 https://ncsslabdatamart.sc.egov.usda.gov/rptExecute.aspx?p=34050&r=2&submit1=Get+Report
## 5 https://ncsslabdatamart.sc.egov.usda.gov/rptExecute.aspx?p=34051&r=2&submit1=Get+Report
## 6 https://ncsslabdatamart.sc.egov.usda.gov/rptExecute.aspx?p=34052&r=2&submit1=Get+Report
## Water_Retention_Report
## 1 https://ncsslabdatamart.sc.egov.usda.gov/rptExecute.aspx?p=34047&r=6&submit1=Get+Report
## 2 https://ncsslabdatamart.sc.egov.usda.gov/rptExecute.aspx?p=34048&r=6&submit1=Get+Report
## 3 https://ncsslabdatamart.sc.egov.usda.gov/rptExecute.aspx?p=34049&r=6&submit1=Get+Report
## 4 https://ncsslabdatamart.sc.egov.usda.gov/rptExecute.aspx?p=34050&r=6&submit1=Get+Report
## 5 https://ncsslabdatamart.sc.egov.usda.gov/rptExecute.aspx?p=34051&r=6&submit1=Get+Report
## 6 https://ncsslabdatamart.sc.egov.usda.gov/rptExecute.aspx?p=34052&r=6&submit1=Get+Report
## Correlation_Report
## 1 https://ncsslabdatamart.sc.egov.usda.gov/rptExecute.aspx?p=34047&r=7&submit1=Get+Report
## 2 https://ncsslabdatamart.sc.egov.usda.gov/rptExecute.aspx?p=34048&r=7&submit1=Get+Report
## 3 https://ncsslabdatamart.sc.egov.usda.gov/rptExecute.aspx?p=34049&r=7&submit1=Get+Report
## 4 https://ncsslabdatamart.sc.egov.usda.gov/rptExecute.aspx?p=34050&r=7&submit1=Get+Report
## 5 https://ncsslabdatamart.sc.egov.usda.gov/rptExecute.aspx?p=34051&r=7&submit1=Get+Report
## 6 https://ncsslabdatamart.sc.egov.usda.gov/rptExecute.aspx?p=34052&r=7&submit1=Get+Report
## pedon_Description_Report
## 1 https://nasis.sc.egov.usda.gov/NasisReportsWebSite/limsreport.aspx?report_name=Pedon_Site_Description_usepedonid&pedon_id=S2007CA009001
## 2 https://nasis.sc.egov.usda.gov/NasisReportsWebSite/limsreport.aspx?report_name=Pedon_Site_Description_usepedonid&pedon_id=S2007CA009002
## 3 https://nasis.sc.egov.usda.gov/NasisReportsWebSite/limsreport.aspx?report_name=Pedon_Site_Description_usepedonid&pedon_id=S2007CA109001
## 4 https://nasis.sc.egov.usda.gov/NasisReportsWebSite/limsreport.aspx?report_name=Pedon_Site_Description_usepedonid&pedon_id=S2007CA109002
## 5 https://nasis.sc.egov.usda.gov/NasisReportsWebSite/limsreport.aspx?report_name=Pedon_Site_Description_usepedonid&pedon_id=S2007CA109003
## 6 https://nasis.sc.egov.usda.gov/NasisReportsWebSite/limsreport.aspx?report_name=Pedon_Site_Description_usepedonid&pedon_id=S2007CA109004
## Soil_Profile
## 1 https://nasis.sc.egov.usda.gov/NasisReportsWebSite/limsreport.aspx?report_name=WEB-profiles-by-PEIID&pedon_peiid=242796
## 2 https://nasis.sc.egov.usda.gov/NasisReportsWebSite/limsreport.aspx?report_name=WEB-profiles-by-PEIID&pedon_peiid=242808
## 3 https://nasis.sc.egov.usda.gov/NasisReportsWebSite/limsreport.aspx?report_name=WEB-profiles-by-PEIID&pedon_peiid=242805
## 4 https://nasis.sc.egov.usda.gov/NasisReportsWebSite/limsreport.aspx?report_name=WEB-profiles-by-PEIID&pedon_peiid=242797
## 5 https://nasis.sc.egov.usda.gov/NasisReportsWebSite/limsreport.aspx?report_name=WEB-profiles-by-PEIID&pedon_peiid=242798
## 6 https://nasis.sc.egov.usda.gov/NasisReportsWebSite/limsreport.aspx?report_name=WEB-profiles-by-PEIID&pedon_peiid=207254
## Soil_web lat
## 1 https://casoilresource.lawr.ucdavis.edu/gmap/?loc=38.3795,-120.442 38.37947
## 2 https://casoilresource.lawr.ucdavis.edu/gmap/?loc=37.9429,-120.715 37.94286
## 3 https://casoilresource.lawr.ucdavis.edu/gmap/?loc=37.8481,-120.561 37.84808
## 4 https://casoilresource.lawr.ucdavis.edu/gmap/?loc=37.8621,-120.509 37.86214
## 5 https://casoilresource.lawr.ucdavis.edu/gmap/?loc=37.8328,-120.516 37.83278
## 6 https://casoilresource.lawr.ucdavis.edu/gmap/?loc=37.9861,-120.236 37.98614
## long latlong user_site_id horizontal_datum_name
## 1 -120.4417 POINT (-120.4417496 38.3794708) 07-SMM-015 NAD83
## 2 -120.7150 POINT (-120.7150269 37.9428596) 07-JCR-002 NAD83
## 3 -120.5607 POINT (-120.5607224 37.8480835) 07-JCR-001 NAD83
## 4 -120.5085 POINT (-120.5085297 37.8621407) 07-SMM-009 NAD83
## 5 -120.5163 POINT (-120.516304 37.8327789) 07-SMM-008 NAD83
## 6 -120.2356 POINT (-120.235611 37.9861374) 06-JCR-006 NAD83
## latitude_direction latitude_degrees latitude_minutes latitude_seconds
## 1 north 38 22 46.1
## 2 north 37 56 34.3
## 3 north 37 50 53.1
## 4 north 37 51 43.7
## 5 north 37 49 58.0
## 6 north 37 59 10.1
## longitude_direction longitude_degrees longitude_minutes longitude_seconds
## 1 west 120 26 30.3
## 2 west 120 42 54.1
## 3 west 120 33 38.6
## 4 west 120 30 30.7
## 5 west 120 30 58.7
## 6 west 120 14 8.2
## latitude_std_decimal_degrees longitude_std_decimal_degrees
## 1 38.37947 -120.4417
## 2 37.94286 -120.7150
## 3 37.84808 -120.5607
## 4 37.86214 -120.5085
## 5 37.83278 -120.5163
## 6 37.98614 -120.2356
## msrepl_tran_version observation_date user_pedon_id
## 1 5f3780b7-ecfb-4a47-8ef5-1f74676c7bba 39177 07CA009001
## 2 44521b48-f3ee-416a-ba8e-2cded5536a70 39174 07CA009002
## 3 557d57b0-a61f-404f-a767-7e95a9c5faf2 39177 07CA109001
## 4 04b0939b-f735-4df7-a365-686602410635 39183 07CA109002
## 5 7f798df9-e551-460e-bf0a-5da3bbf1bd62 39170 07CA109003
## 6 fa26acf5-5cbb-49de-8cff-ea4273dff91c 39023 07CA109004
## pedon_seq_num cntrl_depth_to_top cntrl_depth_to_bot fldsyb mapsyb area_key
## 1 1 28 78 <NA> <NA> 8103
## 2 2 18 68 <NA> <NA> 8103
## 3 1 20 70 <NA> <NA> 8103
## 4 2 12 48 <NA> <NA> 8103
## 5 3 0 36 <NA> <NA> 8103
## 6 4 88 140 <NA> <NA> 8103
## area_type area_sub_type parent_area_key parent_org_key area_code
## 1 ssa <NA> 3951 51 CA630
## 2 ssa <NA> 3951 51 CA630
## 3 ssa <NA> 3951 51 CA630
## 4 ssa <NA> 3951 51 CA630
## 5 ssa <NA> 3951 51 CA630
## 6 ssa <NA> 3951 51 CA630
## area_name
## 1 Central Sierra Foothills Area, California, Parts of Calaveras and Tuolumne Counties
## 2 Central Sierra Foothills Area, California, Parts of Calaveras and Tuolumne Counties
## 3 Central Sierra Foothills Area, California, Parts of Calaveras and Tuolumne Counties
## 4 Central Sierra Foothills Area, California, Parts of Calaveras and Tuolumne Counties
## 5 Central Sierra Foothills Area, California, Parts of Calaveras and Tuolumne Counties
## 6 Central Sierra Foothills Area, California, Parts of Calaveras and Tuolumne Counties
## area_abbrev area_desc
## 1 <NA> <NA>
## 2 <NA> <NA>
## 3 <NA> <NA>
## 4 <NA> <NA>
## 5 <NA> <NA>
## 6 <NA> <NA>Querying by Taxon Name
You can also search by correlated or sampled-as taxon names using a
custom WHERE clause:
# Fetch lab data where the correlated or sampled name is 'Musick' or 'Holland'
# CASE statement handles differences between correlated and sampled names
ldm_taxon <- fetchLDM(WHERE = "(CASE WHEN corr_name IS NOT NULL
THEN LOWER(corr_name)
ELSE LOWER(samp_name)
END) IN ('musick', 'holland')")
print(ldm_taxon)## SoilProfileCollection with 40 profiles and 259 horizons
## profile ID: pedon_key | horizon ID: hzID
## Depth range: 107 - 371 cm
##
## ----- Horizons (6 / 259 rows | 10 / 432 columns) -----
## pedon_key hzID hzn_top hzn_bot hzn_desgn layer_key labsampnum project_key
## 11218 1 0 18 A 73461 84P02435 1061
## 11218 2 18 36 AB 73462 84P02436 1061
## 11218 3 36 64 BAt 73463 84P02437 1061
## 11218 4 64 94 Bt1 73464 84P02438 1061
## 11218 5 94 152 Bt2 73465 84P02439 1061
## 11219 6 0 15 BAt 73466 84P02440 1061
## layer_sequence layer_type
## 1 horizon
## 2 horizon
## 3 horizon
## 4 horizon
## 5 horizon
## 1 horizon
## [... more horizons ...]
##
## ----- Sites (6 / 40 rows | 10 / 126 columns) -----
## pedon_key site_key pedlabsampnum pedoniid upedonid labdatadescflag priority
## 11218 11218 84P0457 1313398 83CA019301 0 B
## 11219 11219 84P0458 1313407 83CA019302 0 B
## 18148 18148 91P0725 1161605 90CA109107 1 B
## 18161 18161 91P0738 1161598 90CA109120 1 B
## 19043 19043 92P0420 65114 92CA039101 0 B
## 19044 19044 92P0421 65115 92CA039102 0 B
## priority2 samp_name samp_class_type
## C Holland series
## C Musick series
## A Musick series
## A Holland series
## C Holland series
## C Holland series
## [... more sites ...]
##
## Spatial Data:
## [EMPTY]Advanced Usage: Specific Tables
By default, fetchLDM() retrieves a standard set of
tables. You can request specific data, such as physical properties,
using the tables argument:
# Fetch physical properties for soils correlated as "Typic Argialbolls"
ldm_phys <- fetchLDM(x = "Typic Argialbolls",
what = "corr_taxsubgrp",
tables = "lab_physical_properties")
# Inspect the available horizon data columns
names(horizons(ldm_phys))## [1] "layer_key" "labsampnum"
## [3] "project_key" "pedon_key"
## [5] "layer_sequence" "layer_type"
## [7] "layer_field_label_1" "layer_field_label_2"
## [9] "layer_field_label_3" "hzn_top"
## [11] "hzn_bot" "hzn_desgn_old"
## [13] "hzn_desgn" "hzn_discontinuity"
## [15] "hzn_master" "hzn_prime"
## [17] "hzn_vert_subdvn" "hzn_desgn_other"
## [19] "non_hzn_desgn" "stratified_textures_flag"
## [21] "texture_description" "result_source_key"
## [23] "prep_code" "texture_lab"
## [25] "particle_size_method" "clay_total"
## [27] "silt_total" "sand_total"
## [29] "clay_fine" "clay_caco3"
## [31] "silt_fine" "silt_coarse"
## [33] "sand_very_fine" "sand_fine"
## [35] "sand_medium" "sand_coarse"
## [37] "sand_very_coarse" "frag_2_5_mm_wt_pct_lt_75"
## [39] "frag__2_20_mm_wt_pct_lt_75" "frag_5_20_mm_wt_pct_lt_75"
## [41] "frag_20_75_mm_wt_pct_lt_75" "total_frag_wt_pct_gt_2_mm_ws"
## [43] "wt_pct_1_tenth_to_75_mm" "bulk_density_tenth_bar"
## [45] "bulk_density_tenth_bar_method" "bulk_density_third_bar"
## [47] "bulk_density_third_bar_method" "bulk_density_oven_dry"
## [49] "bulk_density_oven_dry_method" "bulk_density_lt_2_mm_air_dry"
## [51] "bulk_density_air_dry_method" "bd_third_bar_lt2_reconstituted"
## [53] "bd_thirdbar_reconstituted_method" "bulk_den_ovendry_reconstituted"
## [55] "bulk_de_odreconstituted_method" "bulk_density_field_moist"
## [57] "bulk_density_field_moist_metho" "particle_density_less_than_2mm"
## [59] "particle_density_lt_2mm_method" "particle_density_gt_2_mm"
## [61] "particle_density_gt_2mm_method" "cole_whole_soil"
## [63] "cole_whole_soil_method" "le_third_fifteen_lt2_mm"
## [65] "le_third_fifteen_lt2_metho" "le_third_ovendry_lt_2_mm"
## [67] "le_third_ovendry_lt_2_mm_metho" "le_field_moist_to_oben_dry"
## [69] "le_fm_to_od_method" "water_retention_0_bar_sieve"
## [71] "water_retention_0_bar_method" "water_retention_6_hundredths"
## [73] "water_retention_6_hund_method" "water_retention_10th_bar"
## [75] "water_retention_10th_bar_meth" "water_retention_third_bar"
## [77] "water_retention_thirdbar_metho" "water_retention_1_bar"
## [79] "water_retention_1_bar_method" "water_retention_2_bar"
## [81] "water_retention_2_bar_method" "water_retention_3_bar_sieve"
## [83] "water_retention_3_bar_method" "water_retention_5_bar_sieve"
## [85] "water_retention_5_bar_method" "water_retention_15_bar"
## [87] "water_retention_15_bar_method" "water_retention_field_state"
## [89] "water_retention_field_state_me" "airdry_ovendry_ratio"
## [91] "atterberg_liquid_limit" "atterberg_liquid_limit_method"
## [93] "atterberg_plasticity_index" "plastic_limit"
## [95] "plastic_limit_method" "aggregate_stability_05_2_mm"
## [97] "aggregate_stability_05_2_metho" "le_to_clay_third_bar_to_ovendr"
## [99] "water_15_bar_to_clay_ratio" "cec7_clay_ratio"
## [101] "effective_cec_to_clay_ratio" "psda_ethanol_dispersion_method"
## [103] "sand_total_ethanol_dispersible" "silt_total_ethanol_dispersible"
## [105] "clay_total_ethanol_dispersible" "sand_very_fine_ethanol_dispers"
## [107] "sand_fine_ethanol_dispersible" "sand_medium_ethanol_dispersibl"
## [109] "sand_coarse_ethanol_dispersibl" "sand_very_coarse_ethanol_disp"
## [111] "water_dispersible_fraction_method" "clay_tot_h2o_dispersible"
## [113] "clay_fine_h2o_dispersible" "clay_co3_h2o_dispersible"
## [115] "silt_total_h2o_dispersible" "silt_fine_h2o_dispersible"
## [117] "silt_coarse_h2o_dispersible" "sand_total_h2o_dispersible"
## [119] "sand_vf_h2o_dispersible" "sand_fine_h2o_dispersible"
## [121] "sand_medium_h2o_dispersible" "sand_coarse_h2o_dispersible"
## [123] "sand_vc_h2o_dispersible" "color_pyrophosphate_extract"
## [125] "color_pyrophosphate_method" "bd_thirdbar_before_rewet_organ"
## [127] "bd_before_rewet_organic_method" "bd_thirdbar_rewet_organic_soil"
## [129] "bd_third_rewet_organic_method" "bulk_den_rewet_oven_dry"
## [131] "bulk_den_rewet_oven_dry_method" "mineral_content_loss_on_igniti"
## [133] "mineral_content_loi_method" "estimated_organic_matter"
## [135] "estimated_om_plus_mineral" "fiber_analysis_method"
## [137] "fiber_unrubbed" "fiber_rubbed"
## [139] "decomposition_state" "limnic_material_type"
## [141] "hzID"fetchLDM supports retrieving data from various KSSL
tables, including chemical properties, mineralogy, and x-ray
analysis.
Spatial Queries
This document mainly focuses on details of custom spatial queries
using the low-level SDA_query() function, but there are
several functions that provide high-level convenience interface for
spatial queries in soilDB. First we will discuss converting
spatial data to Well-Known Text for use in generating custom queries.
Then we will discuss the high- and low-level interfaces in
soilDB.
Converting sf Objects to WKT
Important: SDA requires spatial inputs (WKT) to be in WGS84 (EPSG:4326) geographic coordinates.
Passing projected coordinates (like UTM or Albers) will result in query failures or zero results.
SDA does store an alternate projected version of the geometry data
(e.g. mupolygonproj, rather than
mupolygongeo). The projection is a Web Mercator projection
("EPSG:3857") so it is best avoided in analysis, though it
is an option for visualization web map applications that lack capability
to project the data.
You can use sf to define a geometry, such as a bounding
recatangle, and convert it to WKT (Well-Known Text) for spatial
queries:
library(sf)
# Define a bounding box for a region of interest
# (xmin, ymin, xmax, ymax)
bbox <- c(-120.9, 37.7, -120.8, 37.8)
bbox_sf <- st_as_sfc(st_bbox(c(
xmin = bbox[1],
ymin = bbox[2],
xmax = bbox[3],
ymax = bbox[4]
), crs = 4326))
wkt <- st_as_text(bbox_sf)
wkt## [1] "POLYGON ((-120.9 37.7, -120.8 37.7, -120.8 37.8, -120.9 37.8, -120.9 37.7))"High-level Functions
The soilDB package provides two higher-level functions
(SDA_spatialQuery() and fetchSDA_spatial())
that make obtaining spatial data easier. Both of these functions
internally use SDA_query() and are often a better option
for most use cases compared to crafting a custom spatial query.
SDA_spatialQuery(): spatial inputs (e.g. point location, AOI rectangle) => spatial or tabular outputsfetchSDA_spatial(): tabular inputs (e.g. map unit key, area symbol, ecological site ID) => spatial outputs
The functions take different inputs, and support various outputs
including SSURGO and STATSGO2 map unit polygon geometry, special feature
points/lines/polygons, soil survey area boundaries, Major Land Resource
Area (MLRA) boundaries, or simple tabular information using spatial data
as input. These functions will handle projection to
"EPSG:4326" internally as long as the input data has the
correct CRS metadata.
# Example: Retrieve map unit polygons that intersect a bounding box
# This handles the WKT conversion and query construction automatically
# geomIntersection = TRUE clips the polygons to the bounding box
polygons <- SDA_spatialQuery(bbox_sf, what = "mupolygon", geomIntersection = TRUE)
polygons## Simple feature collection with 334 features and 2 fields
## Geometry type: GEOMETRY
## Dimension: XY
## Bounding box: xmin: -120.9 ymin: 37.7 xmax: -120.8 ymax: 37.8
## Geodetic CRS: WGS 84
## First 10 features:
## mukey area_ac geom
## 1 1403416 26.74260 POLYGON ((-120.8998 37.7873...
## 2 1403416 325.55235 POLYGON ((-120.8872 37.7893...
## 3 1403425 53.06925 POLYGON ((-120.8024 37.7863...
## 4 1403413 108.53249 POLYGON ((-120.8788 37.7704...
## 5 1403412 527.89351 POLYGON ((-120.8945 37.7695...
## 6 1403420 82.85632 POLYGON ((-120.8021 37.7895...
## 7 1403421 15.05385 POLYGON ((-120.8565 37.7781...
## 8 1403414 22.79950 POLYGON ((-120.851 37.77987...
## 9 1403416 31.63604 MULTIPOLYGON (((-120.8985 3...
## 10 1403413 20.90871 POLYGON ((-120.8963 37.7686...This section will be expanded in the future, but for now an example application of the two higher-level function is available in the “Dominant Ecological Site” vignette.
Spatial Queries: The Two-Step Pattern
For optimal performance, separate your spatial and tabular queries.
Fetch the list of intersecting map unit keys (mukey) first,
then use those keys to query attribute tables.
This avoids joining heavy geometry columns with complex attribute tables, which can trigger the 32Mb serialization limit. Then we can use the WKT in a custom SDA query to get map units intersecting the bounding box:
# Step 1: Get the mukeys that intersect the bounding box
q <- sprintf("
SELECT DISTINCT mu.mukey
FROM mapunit AS mu
INNER JOIN mupolygon AS mp ON mp.mukey = mu.mukey
WHERE mp.mupolygongeo.STIntersects(geometry::STGeomFromText('%s', 4326)) = 1
", wkt)
spatial_result <- SDA_query(q)
head(spatial_result, 5)## mukey
## 1 462527
## 2 462554
## 3 462555
## 4 462558
## 5 462566This query uses special geospatial functions defined in SQL Server to perform the geometric operations (in this case “intersection”)
SDA Spatial Helper Functions
In addition to standard T-SQL spatial functions, SDA provides pre-defined Table-Valued Functions (TVFs) optimized for intersections.
-
SDA_Get_Mukey_from_intersection_with_WktWgs84(wkt): Returnsmukeyvalues intersecting the input WKT. -
SDA_Get_MupolygonWktWgs84_from_Mukey(mukey): Returns WKT geometry for a specificmukey.
This makes the logic much simpler for the common operations of
finding mukey given a spatial location or geometry:
# Input MUST be WKT in WGS84 (EPSG:4326)
q <- "SELECT * FROM SDA_Get_Mukey_from_intersection_with_WktWgs84('POINT(-120.9 37.7)')"
result <- SDA_query(q)Also, you can do the inverse (map unit key to geometry):
# Step 2: Get Geometry from Map Unit Key (mukey)
# Useful for retrieving the polygon boundary for a specific map unit
target_mukey <- 461994
q <- sprintf("SELECT * FROM SDA_Get_MupolygonWktWgs84_from_Mukey('%s')", target_mukey)
# Result contains the mukey and the geometry in WKT format
geometry_df <- SDA_query(q)
head(geometry_df)## MupolygonWktWgs84
## 1 POLYGON ((-121.032455555662 37.9592152603984, -121.03285202503 37.9591849129885, -121.033072907654 37.9591081653858, -121.033328454278 37.9589770304221, -121.033728769482 37.9588035660117, -121.033900712322 37.9587435334631, -121.034102285527 37.9587105626138, -121.034226937322 37.9587131055087, -121.034372855748 37.9587426135551, -121.034498021914 37.9588254436972, -121.034637122971 37.9588730126591, -121.034725363384 37.9588563818132, -121.034868509489 37.9590389438022, -121.034869562297 37.9591653228325, -121.03475359382 37.9593522473175, -121.034173981163 37.9596399606279, -121.033980610935 37.9597719381858, -121.032316040062 37.961123123151, -121.032060957959 37.9612624734441, -121.031769961277 37.9613566706344, -121.031605303085 37.9614890992556, -121.031372905269 37.961926794296, -121.031278725938 37.962186772691, -121.031253880828 37.9624202209759, -121.030979949929 37.963433991072, -121.030853664442 37.964009330753, -121.030613352925 37.9642666362517, -121.029817684926 37.9645320941986, -121.029575343951 37.9644922710971, -121.029447384597 37.9642917390781, -121.029472874344 37.963967598828, -121.029415124536 37.9637773179969, -121.029447904803 37.9635255769229, -121.029781358193 37.9629641602046, -121.029924150065 37.9626145365407, -121.030001933825 37.9621565455648, -121.029944756724 37.9620021837882, -121.029825937826 37.9618108279156, -121.029767043665 37.9615487094568, -121.029807213431 37.9613148261005, -121.029769648729 37.9610353050336, -121.029996887309 37.9608500418744, -121.030561206747 37.9604805411635, -121.030732846467 37.9602311429487, -121.03109388638 37.9595881670532, -121.031321316698 37.9593760614507, -121.031430649793 37.9592968000317, -121.031652007924 37.9592282724891, -121.031900776861 37.9591872716173, -121.032455555662 37.9592152603984))
## 2 POLYGON ((-120.977440277027 37.8400202039719, -120.977735828159 37.8398271562088, -120.977918761599 37.8396863165759, -120.978089096334 37.8394815881836, -120.978189004401 37.839275889939, -120.978286303194 37.8389081212846, -120.978279774157 37.8385389812703, -120.978301713885 37.8381250774638, -120.97823247016 37.8377635179397, -120.978084402863 37.8372290429494, -120.977901893339 37.8370002134407, -120.977557934853 37.8364901013732, -120.97725676047 37.8359525569539, -120.977205941479 37.8357266595, -120.977202148334 37.8355371188211, -120.97746648077 37.834821175063, -120.977614815185 37.8346524635618, -120.977758216532 37.8344385863328, -120.97803793374 37.8342719453342, -120.978248634626 37.8341049638797, -120.978397090106 37.8339537805788, -120.978723965594 37.8335629096373, -120.978804868982 37.8333297714404, -120.978860203523 37.8329162686792, -120.978716374806 37.8325176537409, -120.978649511054 37.8324170767535, -120.978572686261 37.8320644960726, -120.97856319208 37.8318207102925, -120.978589049034 37.8316138758532, -120.978824752425 37.8312032773233, -120.978988121178 37.8309990766935, -120.979217329881 37.8306692963475, -120.979303459649 37.8304821847855, -120.979301423206 37.8302118906905, -120.979187675825 37.830020415361, -120.979112886686 37.8299381289761, -120.978948686889 37.8298274341976, -120.978779132488 37.8296531828803, -120.978529093434 37.8293423995408, -120.978491819954 37.8291247549243, -120.978544129924 37.8289188513919, -120.978646331634 37.8286683190097, -120.978677244149 37.8285241791737, -120.978954614895 37.8278082658793, -120.978977475239 37.8276648871392, -120.978967419536 37.8274572529753, -120.978799771258 37.827147705694, -120.978630303077 37.8270011561598, -120.978480434303 37.826835720976, -120.978024032673 37.8264674195749, -120.977824916161 37.8263381624385, -120.9777613674 37.8261029186895, -120.977793060477 37.8258957866904, -120.97794896038 37.825718095457, -120.978220141663 37.8256779676964, -120.978467354419 37.8257814498629, -120.978692923239 37.8259116369393, -120.978891697534 37.826050203977, -120.979159355796 37.8261715808214, -120.979490920784 37.8262407743618, -120.979836341971 37.8262470092522, -120.980204216951 37.8262254440749, -120.980815245795 37.8261548276568, -120.981098727404 37.8261777203038, -120.981387006712 37.8263003203597, -120.981520421313 37.826572681762, -120.981545320834 37.8266995967704, -120.981532882231 37.8269692269045, -120.981391196465 37.8275347861969, -120.981257240825 37.8279647516823, -120.981217960856 37.8282529354896, -120.98124735985 37.828478696968, -120.981311127445 37.8287591700524, -120.981384021796 37.8289767510116, -120.981387961865 37.8291117492463, -120.981096081815 37.8298371765903, -120.981003698192 37.8300061963217, -120.980539929736 37.830674278857, -120.980135048729 37.8312173090063, -120.98005338666 37.8314413687206, -120.979986486042 37.8320171399379, -120.979941980294 37.8321872243406, -120.979944579446 37.8324213665481, -120.9799007269 37.8325109295029, -120.979918930859 37.8326734324694, -120.979970534168 37.8328363366954, -120.980057707982 37.8330093513418, -120.980312904842 37.8334105279939, -120.980536646829 37.8336658343484, -120.980686751617 37.8338044263142, -120.980912131345 37.8339614495489, -120.981266005293 37.8343456682067, -120.9813572608 37.8345991374574, -120.981449934201 37.8347811646841, -120.981501530914 37.8350161398622, -120.981454115343 37.8352773826639, -120.981359406411 37.8355633074607, -120.981126752857 37.836082299963, -120.980943137716 37.8363138387317, -120.980752540785 37.8365080317902, -120.980296812808 37.8367530942482, -120.980202533009 37.8369853371646, -120.979995036867 37.8373161153888, -120.979824756851 37.8375106736617, -120.979476083896 37.8379827951916, -120.979337943284 37.8383046000667, -120.979065401171 37.8387598625711, -120.978901454605 37.8390002147039, -120.978771674242 37.8392500476565, -120.978666996045 37.8396720268917, -120.978645618909 37.8400497789281, -120.978725416744 37.8402770044867, -120.978556685386 37.840345576608, -120.977994970428 37.8403633352033, -120.977780754313 37.8403416371155, -120.977663765668 37.8403125285352, -120.977602251142 37.8402755073615, -120.977508129714 37.8401030205027, -120.977440277027 37.8400202039719))
## 3 POLYGON ((-120.985523088218 37.9059362513452, -120.985891567239 37.9059598999602, -120.986299486427 37.9060390524287, -120.986459355563 37.9060508909253, -120.986639996869 37.9060094145871, -120.987041369765 37.9058533983687, -120.987208918771 37.905811887389, -120.987458299277 37.9057800557708, -120.987652493843 37.9058189001273, -120.988233780422 37.906216589848, -120.98843454242 37.9062743869922, -120.988843574818 37.9063532990626, -120.989217084966 37.9064498037916, -120.989389701677 37.9065430539036, -120.989583343109 37.9066180464921, -120.989722527941 37.9067108974974, -120.989854249232 37.906830256895, -120.989915949246 37.9069568710404, -120.989825322146 37.9071449150441, -120.989491922873 37.9073015057732, -120.989436188876 37.9072641929805, -120.989346680326 37.9072357926623, -120.989124330051 37.9073044762055, -120.988895623832 37.9073994359224, -120.988222545241 37.907766589578, -120.987944370208 37.9078423266246, -120.987785562334 37.907840430903, -120.987543137214 37.9077275919775, -120.987376313195 37.9077162847434, -120.987182918211 37.9077484171905, -120.986960133373 37.9078707769975, -120.986835303725 37.907977269445, -120.98664837129 37.9082168655059, -120.986480550665 37.9083674591968, -120.986258536355 37.9084268263362, -120.986092945979 37.9084328143834, -120.985711622244 37.9083721196174, -120.985516856291 37.908441494137, -120.985420000626 37.9085291988148, -120.985342444448 37.908789344077, -120.985127005318 37.9091457732408, -120.984973312415 37.9095225516516, -120.984402502985 37.9105935975282, -120.984131761949 37.9107869589363, -120.984034685975 37.9105513221075, -120.98390352642 37.9103958052679, -120.98346043993 37.9100366434719, -120.983259762883 37.9099344691991, -120.983108389692 37.9097961142513, -120.983018134086 37.909614488707, -120.982984170679 37.9094340275789, -120.982970467749 37.9092262309921, -120.983005464254 37.9090285780751, -120.983069584541 37.908849781913, -120.983118665735 37.9085623317296, -120.983208742576 37.9084825146724, -120.984131089911 37.9082822469208, -120.984526413222 37.9082254475723, -120.984686087165 37.9081199871405, -120.984756252956 37.9079861228242, -120.984707787014 37.9078049983975, -120.984576505041 37.9076319532808, -120.984383351417 37.9074210291711, -120.984286486804 37.9072306229818, -120.984224290109 37.907057913864, -120.984301713878 37.9068523109911, -120.98438517861 37.9067637115338, -120.984550908203 37.9066311133469, -120.984752369443 37.906526152798, -120.985002185842 37.9064406459829, -120.985183304963 37.9063353188541, -120.985294574459 37.9062205763299, -120.985377954947 37.9061042745238, -120.985440400018 37.905961860195, -120.985523088218 37.9059362513452))
## 4 POLYGON ((-120.98392012538 37.9120092608573, -120.983920116288 37.9120813314766, -120.983877330105 37.9121706626422, -120.983863795059 37.9122963792718, -120.983890819501 37.9124052990935, -120.983876490532 37.9127381482558, -120.983897239166 37.9129010459885, -120.984000810323 37.9130558648315, -120.984068854303 37.9132282760937, -120.984061793966 37.9134173159296, -120.983999205165 37.9136142710604, -120.983970756462 37.9139750195284, -120.983990431669 37.9142000469498, -120.983920114666 37.9144605229553, -120.983733834268 37.9144033823299, -120.983512151504 37.9143813626691, -120.983276402284 37.9143049985795, -120.98315192843 37.9141859642132, -120.983138874876 37.913897647622, -120.983027640279 37.9136520350459, -120.982827089637 37.9134953184344, -120.98263433916 37.9133748528511, -120.982281177519 37.9130624826414, -120.981983911426 37.9125887446493, -120.981831632573 37.9124958505786, -120.981554726659 37.9124826032185, -120.981187656278 37.9125214691775, -120.980937266457 37.9125710487223, -120.980701936796 37.9125851407342, -120.980507772493 37.9125361126669, -120.980501406417 37.9123563496652, -120.980578329891 37.9121767278483, -120.980550867476 37.9119154482948, -120.980717599403 37.9117650946736, -120.981404770214 37.9117406093536, -120.981805901404 37.9117657645214, -120.98213205474 37.9118250747223, -120.982450263095 37.9119747450009, -120.982838978153 37.9120533107828, -120.98311617122 37.9121394874135, -120.983378532244 37.9121622400764, -120.983565925004 37.9121470787842, -120.983726240308 37.9121052406898, -120.98392012538 37.9120092608573))
## 5 POLYGON ((-120.976618752919 37.8950135458249, -120.976335244308 37.8948917321003, -120.976321844539 37.8947568666454, -120.97644103155 37.8943078568389, -120.976406106564 37.8941451541604, -120.97632346141 37.8940266151981, -120.97582601447 37.8935134340163, -120.975695104895 37.8934031386057, -120.975515164428 37.8932920075564, -120.975141114774 37.8931318394823, -120.974835950129 37.893036726673, -120.974399641239 37.8929302273106, -120.974137351298 37.8929074553091, -120.973776312456 37.8929016327187, -120.97339529942 37.8928140592313, -120.973090825587 37.8927003197221, -120.972862223499 37.8925069662265, -120.972606115165 37.8923406135282, -120.972392314346 37.8922827548895, -120.972128697888 37.8922870504914, -120.971414098739 37.8923828538791, -120.97071429361 37.8926141490595, -120.970346506972 37.8927880449445, -120.970089249558 37.8927660604654, -120.970090747333 37.8926123758252, -120.970194007042 37.8924882346052, -120.970312007212 37.8923998167057, -120.970659111067 37.8922348638255, -120.971117728715 37.8919902380063, -120.971339361943 37.8919402093411, -120.971651463785 37.8919008329444, -120.971922028594 37.891896009406, -120.972254025244 37.8919106798158, -120.972593814151 37.8919616014651, -120.973140557808 37.8921605087601, -120.973556944765 37.8922850354301, -120.973806065242 37.892280071726, -120.974054984254 37.8922298767936, -120.974444063149 37.8921106474734, -120.974707678843 37.8921063468797, -120.975143842044 37.8922673870532, -120.976831996534 37.8932153157039, -120.976970295455 37.8932714003401, -120.97713624351 37.8934279569021, -120.977364047673 37.8938284355726, -120.977314296968 37.8941964046634, -120.977237165285 37.894402865158, -120.977251411437 37.8945745116158, -120.977465674558 37.8947126503714, -120.977803670201 37.8948544825232, -120.978116546977 37.8950302087813, -120.978205525081 37.8952666121033, -120.978108538929 37.8954088530654, -120.977989558961 37.8955150392216, -120.97784419553 37.8955759250091, -120.977635660701 37.8955539294061, -120.977484187976 37.8954701090048, -120.97694512638 37.8950737316129, -120.976618752919 37.8950135458249))
## 6 POLYGON ((-120.958148228164 37.8929009967531, -120.958257566342 37.89339922832, -120.958242554141 37.8937682268486, -120.958152399799 37.893992167427, -120.958207050548 37.8941913968848, -120.958255178651 37.894299599785, -120.958337901348 37.8943737818444, -120.958406631387 37.8945552874435, -120.95827453497 37.8946614175666, -120.957956155354 37.8946826657254, -120.957588087146 37.8946496217747, -120.957192552933 37.8946334017232, -120.956721843593 37.894544192444, -120.956410676599 37.8944659975247, -120.956058396377 37.8940730302104, -120.956079378789 37.8938931079596, -120.956371088193 37.8938256981606, -120.956911733464 37.8938799710885, -120.95711167439 37.8939287402782, -120.957326802893 37.8939595538745, -120.957569551839 37.8939190001486, -120.957736981051 37.8937500551254, -120.957757993901 37.8934980617213, -120.957702914505 37.8932185433083, -120.957663591713 37.8927130748242, -120.957693027833 37.8921451979903, -120.957590286763 37.8915938506515, -120.957549456741 37.8914758081609, -120.957486835947 37.8913669379693, -120.957135291263 37.89088328039, -120.957128531351 37.8907571957377, -120.957185224437 37.8906049191925, -120.957268166577 37.8904804183495, -120.957282434107 37.8903360819168, -120.957138383743 37.8899642861266, -120.956883152836 37.8894909945394, -120.957056677266 37.8893946863583, -120.957257940983 37.8894163835871, -120.957568148277 37.8896740078802, -120.957623281227 37.8897474865796, -120.957809306399 37.8901650217306, -120.957896776288 37.8913561222369, -120.957875227461 37.8915721961394, -120.957929495688 37.8918528078143, -120.957962159765 37.8925555331955, -120.958010396191 37.8927912105813, -120.958148228164 37.8929009967531))Using the sf (or terra) package, you can
convert the resulting text WKT column to a spatial object:
if (requireNamespace("sf", quietly = TRUE) &&
!is.null(geometry_df)) {
# Parse WKT column (usually named 'mupolygongeo' in mupolygon table, but 'MupolygonWktWgs84' in TVF result)
poly_sf <- sf::st_as_sfc(geometry_df$MupolygonWktWgs84, crs = 4326)
plot(poly_sf, main = paste("Geometry for mukey=", target_mukey))
}
Note: The TVF function name implies the CRS is WGS84
(authority:code EPSG:4326, SRS ID 4326; or,
more correctly, OGC:CRS84).
See the SDA Advanced Query Guide for more details on TVF functions and other high-level features built into SDA.
Spatial and Tabular Property Integration
We can use the result of our spatial filtering with property queries.
Here we extract the unique map unit keys and pass as
mukeys argument to get_SDA_property()
# Step 2: Use the mukeys to fetch tabular data
# First, get mukeys in bounding box
spatial_mukeys <- unique(spatial_result$mukey)
# Then query properties for those mukeys
if (length(spatial_mukeys) > 0) {
clay_in_bbox <- get_SDA_property(
property = "Total Clay - Rep Value",
method = "Weighted Average",
mukeys = spatial_mukeys,
top_depth = 0,
bottom_depth = 50
)
head(clay_in_bbox)
}## mukey areasymbol musym
## 1 1403410 CA632 127
## 2 1403412 CA632 130
## 3 1403413 CA632 131
## 4 1403414 CA632 134
## 5 2766111 CA632 142
## 6 1403416 CA632 157
## muname
## 1 Chuloak sandy loam, 0 to 2 percent slopes
## 2 Columbia sandy loam, drained, 0 to 2 percent slopes, rarely flooded
## 3 Columbia sandy loam, partially drained, 0 to 2 percent slopes, occasionally flooded
## 4 Cometa sandy loam, 2 to 8 percent slopes
## 5 Delhi loamy sand, 0 to 2 percent slopes, MLRA 17
## 6 Exeter sandy clay loam, 0 to 2 percent slopes
## claytotal_r
## 1 17.80
## 2 17.08
## 3 15.38
## 4 20.00
## 5 2.22
## 6 18.60This shows how to get the data, see the Local SSURGO vignette for more spatial
visualization examples using sf.
Integration Examples: Combining Multiple Functions
Example 1: Multi-Method Property Comparison
Compare the same property using different aggregation methods:
# Get clay content using three different methods
methods <- c("Dominant Component (Numeric)", "Weighted Average", "Max")
clay_results <- data.frame()
for (method in methods) {
result <- get_SDA_property(
property = "Total Clay - Rep Value",
method = method,
areasymbols = "CA630",
top_depth = 0,
bottom_depth = 50
)
result$method <- method
clay_results <- rbind(clay_results, result)
}
# compare methods for a single map unit
subset(clay_results, mukey == 1865918)## mukey areasymbol musym
## 17 1865918 CA630 3046
## 146 1865918 CA630 3046
## 259 1865918 CA630 3046
## muname claytotal_r
## 17 Goldwall-Toomes-Rock outcrop complex, 1 to 8 percent slopes 10.00000
## 146 Goldwall-Toomes-Rock outcrop complex, 1 to 8 percent slopes 10.76712
## 259 Goldwall-Toomes-Rock outcrop complex, 1 to 8 percent slopes 12.00000
## method
## 17 Dominant Component (Numeric)
## 146 Weighted Average
## 259 MaxExample 2: Properties and Interpretations for Land Use Planning
Combine soil properties and interpretations for a land use suitability assessment:
# Get drainage class and hydrologic group
drain_hydro <- get_SDA_property(
property = c("Drainage Class", "Hydrologic Group"),
method = "Dominant Condition",
areasymbols = "CA630"
)
# Get an engineering interpretation
eng_interp <- get_SDA_interpretation(
rulename = "ENG - Septic Tank Absorption Fields",
method = "Dominant Condition",
areasymbols = "CA630"
)
# Explicitly merge on mukey (and other shared columns to avoid duplication)
suitability <- merge(drain_hydro, eng_interp,
by = c("mukey", "areasymbol", "musym", "muname"))
head(suitability)## mukey areasymbol musym
## 1 1865918 CA630 3046
## 2 1865926 CA630 7088
## 3 1865927 CA630 7155
## 4 1865928 CA630 7156
## 5 1865929 CA630 8033
## 6 1865930 CA630 8034
## muname
## 1 Goldwall-Toomes-Rock outcrop complex, 1 to 8 percent slopes
## 2 Loafercreek-Gopheridge complex, 30 to 60 percent slopes
## 3 Crimeahouse-Sixbit complex, 3 to 15 percent slopes
## 4 Crimeahouse-Sixbit complex, 15 to 30 percent slopes
## 5 Copperopolis-Whiterock complex, 2 to 8 percent slopes, rocky
## 6 Copperopolis-Whiterock complex, 3 to 15 percent slopes, rocky
## drainagecl hydgrp rating_ENGSepticTankAbsorptionFields
## 1 Moderately well drained D 1
## 2 Well drained C 1
## 3 Well drained C 1
## 4 Well drained C 1
## 5 Well drained D 1
## 6 Well drained D 1
## total_comppct_ENGSepticTankAbsorptionFields
## 1 80
## 2 94
## 3 97
## 4 94
## 5 88
## 6 90
## class_ENGSepticTankAbsorptionFields
## 1 Very limited
## 2 Very limited
## 3 Very limited
## 4 Very limited
## 5 Very limited
## 6 Very limited
## reason_ENGSepticTankAbsorptionFields
## 1 Ponded > 4 hours "Ponding" (1); Shallow to Bedrock 100 - 180cm "Depth to bedrock" (1); Wet, Ground Water Near the Surface (120 - 180cm) "Depth to saturated zone" (1)
## 2 Shallow to Bedrock 100 - 180cm "Depth to bedrock" (1); Slope 8 to > 15% "Slope" (1)
## 3 Shallow to Bedrock 100 - 180cm "Depth to bedrock" (1); Slope 8 to > 15% "Slope" (0.633); Percolation 60 - 180cm (24-72") "Slow water movement" (0.498); Large Stones - Fract. >3in, 24.9 to >50%, Wght. Av. 0-40 "Large stones" (0.004)
## 4 Shallow to Bedrock 100 - 180cm "Depth to bedrock" (1); Slope 8 to > 15% "Slope" (1); Large Stones - Fract. >3in, 24.9 to >50%, Wght. Av. 0-40 "Large stones" (0.13)
## 5 Shallow to Bedrock 100 - 180cm "Depth to bedrock" (1)
## 6 Shallow to Bedrock 100 - 180cm "Depth to bedrock" (1); Slope 8 to > 15% "Slope" (0.367)Example 3: Hydric Status and Interpretations
Combine hydric classifications with wetland-related interpretations:
# Get a generalized mapunit-level hydric classification
# see ?get_SDA_hydric for details on method="mapunit"
hydric_stat <- get_SDA_hydric(
areasymbols = "CA077",
method = "MAPUNIT"
)
wet_interp <- get_SDA_interpretation(
rulename = "WMS - Excavated Ponds (Aquifer-fed)",
method = "Dominant Condition",
areasymbols = "CA077"
)
wetland_assess <- merge(hydric_stat, wet_interp,
by = c("mukey", "areasymbol", "musym", "muname"),
all.x = TRUE)
subset(wetland_assess, rating_WMSExcavatedPondsAquiferfed < 0.6)## mukey areasymbol musym
## 66 462051 CA077 159
## 111 462096 CA077 204
## 112 462097 CA077 205
## 131 462116 CA077 224
## 132 462117 CA077 225
## 137 462122 CA077 230
## 138 462123 CA077 231
## 140 462125 CA077 233
## 168 462153 CA077 261
## 170 462155 CA077 263
## 171 462156 CA077 264
## muname
## 66 Fluvaquents, 0 to 2 percent slopes, frequently flooded, MLRA 16
## 111 Peltier mucky clay loam, partially drained, 0 to 2 percent slopes, MLRA 16
## 112 Peltier mucky clay loam, organic substratum, partially drained, 0 to 2 percent slopes
## 131 Rindge mucky silt loam, partially drained, 0 to 2 percent slopes, MLRA 16
## 132 Rindge muck, 0 to 2 percent slopes, partially drained, MLRA 16
## 137 Ryde clay loam, partially drained, 0 to 2 percent slopes, MLRA 16
## 138 Ryde silty clay loam, organic substratum, partially drained, 0 to 2 percent slopes, MLRA 16
## 140 Ryde-Peltier complex, partially drained, 0 to 2 percent slopes, MLRA 16
## 168 Valdez silt loam, organic substratum, partially drained, 0 to 2 percent slopes, MLRA 16
## 170 Venice mucky silt loam, partially drained, 0 to 2 percent slopes, overwashed
## 171 Venice muck, partially drained, 0 to 2 percent slopes, MLRA 16
## total_comppct hydric_majors hydric_inclusions HYDRIC_RATING
## 66 100 85 15 Hydric
## 111 100 85 15 Hydric
## 112 100 85 12 Predominantly Hydric
## 131 100 85 15 Hydric
## 132 100 85 15 Hydric
## 137 100 85 15 Hydric
## 138 100 85 15 Hydric
## 140 100 85 15 Hydric
## 168 100 85 15 Hydric
## 170 100 85 15 Hydric
## 171 100 85 15 Hydric
## rating_WMSExcavatedPondsAquiferfed
## 66 0.30
## 111 0.54
## 112 0.54
## 131 0.48
## 132 0.10
## 137 0.54
## 138 0.54
## 140 0.54
## 168 0.54
## 170 0.54
## 171 0.54
## total_comppct_WMSExcavatedPondsAquiferfed class_WMSExcavatedPondsAquiferfed
## 66 96 Somewhat limited
## 111 85 Somewhat limited
## 112 85 Somewhat limited
## 131 93 Somewhat limited
## 132 85 Somewhat limited
## 137 85 Somewhat limited
## 138 89 Somewhat limited
## 140 85 Somewhat limited
## 168 85 Somewhat limited
## 170 85 Somewhat limited
## 171 100 Somewhat limited
## reason_WMSExcavatedPondsAquiferfed
## 66 Cutbank Caving and Apparent Water Table "Unstable excavation walls" (0.1)
## 111 Deep to Apparent Water Table "Depth to saturated zone" (0.543); Percolation Rate (Layers Within an Apparent Water Table) "Slow refill" (0.296); Cutbank Caving and Apparent Water Table "Unstable excavation walls" (0.1)
## 112 Deep to Apparent Water Table "Depth to saturated zone" (0.543); Cutbank Caving and Apparent Water Table "Unstable excavation walls" (0.5)
## 131 Cutbank Caving and Apparent Water Table "Unstable excavation walls" (0.1)
## 132 Cutbank Caving and Apparent Water Table "Unstable excavation walls" (0.1)
## 137 Deep to Apparent Water Table "Depth to saturated zone" (0.543); Cutbank Caving and Apparent Water Table "Unstable excavation walls" (0.5); Percolation Rate (Layers Within an Apparent Water Table) "Slow refill" (0.296)
## 138 Deep to Apparent Water Table "Depth to saturated zone" (0.543); Cutbank Caving and Apparent Water Table "Unstable excavation walls" (0.5)
## 140 Deep to Apparent Water Table "Depth to saturated zone" (0.543); Cutbank Caving and Apparent Water Table "Unstable excavation walls" (0.5); Percolation Rate (Layers Within an Apparent Water Table) "Slow refill" (0.296)
## 168 Deep to Apparent Water Table "Depth to saturated zone" (0.543); Cutbank Caving and Apparent Water Table "Unstable excavation walls" (0.5)
## 170 Deep to Apparent Water Table "Depth to saturated zone" (0.543); Cutbank Caving and Apparent Water Table "Unstable excavation walls" (0.1)
## 171 Deep to Apparent Water Table "Depth to saturated zone" (0.543); Cutbank Caving and Apparent Water Table "Unstable excavation walls" (0.1)Example 4: Aggregating Across Multiple Areas
Here we use base R aggregate() (feel free to swap in
your favorite R aggregation method e.g. dplyr,
data.table, or collapse) to summarize across
survey areas:
# Get properties for two areas
props_ca630 <- get_SDA_property(
property = "Total Clay - Rep Value",
method = "Dominant Component (Numeric)",
areasymbols = "CA630"
)
props_ca649 <- get_SDA_property(
property = "Total Clay - Rep Value",
method = "Dominant Component (Numeric)",
areasymbols = "CA649"
)
# Combine
all_props <- rbind(props_ca630, props_ca649)
# Aggregate by area symbol
area_summary <- aggregate(
claytotal_r ~ areasymbol,
data = all_props,
FUN = function(x) {
c(
mean = mean(x, na.rm = TRUE),
median = median(x, na.rm = TRUE),
sd = sd(x, na.rm = TRUE),
n = sum(!is.na(x))
)
}
)
area_summary## areasymbol claytotal_r.mean claytotal_r.median claytotal_r.sd claytotal_r.n
## 1 CA630 23.646480 23.283968 8.779233 126.000000
## 2 CA649 24.484864 24.710145 8.016048 85.000000Example 5: Component-Level Analysis
Use method = "None" to perform custom component-level
analysis:
# Get all component properties without aggregation
clay_by_comp <- get_SDA_property(
property = "Total Clay - Rep Value",
method = "None",
areasymbols = "CA630",
top_depth = 0,
bottom_depth = 25,
include_minors = TRUE
)
head(clay_by_comp)## mukey cokey areasymbol musym
## 1 1865918 26411696 CA630 3046
## 2 1865918 26411696 CA630 3046
## 3 1865918 26411695 CA630 3046
## 4 1865918 26411695 CA630 3046
## 5 1865918 26411695 CA630 3046
## 6 1865918 26411698 CA630 3046
## muname compname
## 1 Goldwall-Toomes-Rock outcrop complex, 1 to 8 percent slopes Goldwall
## 2 Goldwall-Toomes-Rock outcrop complex, 1 to 8 percent slopes Goldwall
## 3 Goldwall-Toomes-Rock outcrop complex, 1 to 8 percent slopes Toomes
## 4 Goldwall-Toomes-Rock outcrop complex, 1 to 8 percent slopes Toomes
## 5 Goldwall-Toomes-Rock outcrop complex, 1 to 8 percent slopes Toomes
## 6 Goldwall-Toomes-Rock outcrop complex, 1 to 8 percent slopes Ultic Argixerolls
## compkind comppct_r majcompflag chkey hzdept_r hzdepb_r
## 1 Series 45 Yes 78806274 0 15
## 2 Series 45 Yes 78806273 15 200
## 3 Series 28 Yes 78806272 0 2
## 4 Series 28 Yes 78806271 2 33
## 5 Series 28 Yes 78806270 33 200
## 6 Taxon above family 5 No 78806281 0 25
## claytotal_r
## 1 10
## 2 NA
## 3 12
## 4 12
## 5 NA
## 6 15
# Calculate average clay by major vs. minor components
clay_summary <- aggregate(
claytotal_r ~ majcompflag,
data = clay_by_comp,
FUN = mean
)
clay_summary## majcompflag claytotal_r
## 1 No 22.94837
## 2 Yes 22.63659Summary and Best Practices
Key Takeaways
-
Use
SDA_query()for custom SQL queries when predefined functions don’t fit your needs -
T-SQL syntax: Use
TOP,ISNULL(),CAST()for SDA queries - Query limits: Keep result sets < 100k records and < 32 Mb; use chunking for large datasets
-
Aggregation methods: Choose an appropriate method
(
Dominant Component,Weighted Average,None, etc.) for your analysis -
Local vs. remote: Use
dsnparameter to query local SSURGO databases (see Local SSURGO vignette) -
Spatial queries: Combine WKT geometry with
SDA_query()for location-based searches (or useSDA_spatialQuery())
Recommended Workflow
- Start with small test queries using e.g.
TOP 10, or a small number of inputs, to verify syntax and result table structure - Use
query_string = TRUEto inspect generated SQL - Scale up with
areasymbolsormukeysparameters - Use chunking for “large” data sets (greater than ~10,000 items, see
makeChunks()section for suggested chunk sizes) - Cache results locally if repeating queries
- Refer to official SDA documentation for table/column details
SDA Resources
- SDA Table Relationships Diagram: https://sdmdataaccess.sc.egov.usda.gov/documents/TableRelationshipsDiagram.pdf
- Column Descriptions: https://www.nrcs.usda.gov/sites/default/files/2022-08/SSURGO-Metadata-Table-Column-Descriptions-Report.pdf
- SDA Query Help
- SDA Query Samples
- SDA Table/Column Descriptions
- soilDB Reference Index
- Local SSURGO Vignette - For creating and querying local SSURGO databases
- Dominant Ecological Sites Vignette - For a fully worked example of combining spatial data with tabular (Ecological Site) data to make thematic maps
Appendix: Common SDA Tables and Columns
Core Tables
| Table | Primary Key | Parent Table | Description |
|---|---|---|---|
legend |
lkey |
N/A | Soil survey area (e.g., CA630) |
mapunit |
mukey |
legend |
Delineated soil mapping unit |
component |
cokey |
mapunit |
Soil component within a map unit |
chorizon |
chkey |
component |
Soil horizon within a component |
cointerp |
cointerpkey |
component |
Component-level interpretations |
coecoclass |
coecoclasskey |
component |
Component ecological classes |
copmgrp |
copmgrpkey |
component |
Component parent material groups |
mupolygon |
mupolygonkey |
N/A | Map unit polygons |
Common Columns
| Column | Table | Description | Example |
|---|---|---|---|
areasymbol |
legend | Soil survey area code | “CA630” |
musym |
mapunit | Map unit symbol | “7159” |
muname |
mapunit | Map unit name | “Sierra coarse sandy loam, 3 to 8 percent slopes” |
compname |
component | Component/soil series name | “Sierra” |
comppct_r |
component | Component percentage (representative) | 85 |
majcompflag |
component | Major component flag | “Yes”/“No” |
claytotal_r |
chorizon | Total clay percentage | 12.5 |
hzdept_r |
chorizon | Horizon depth top (cm) | 0 |
hzdepb_r |
chorizon | Horizon depth bottom (cm) | 25 |
hydricrating |
component | Hydric soil status | “Yes”/“No” |
mrulename |
cointerp | Interpretation rule name | “FOR - Mechanical Planting Suitability” |
interphr |
cointerp | Interpretation rating/class | “Somewhat Limited” |
mupolygongeo |
mupolygon | Map unit polygon geometry (WKT; WGS84 geographic coordinates in decimal degrees) | “POLYGON (…)” |
